Fi Overview:
Fi is a high quality product with high definition and super clear image. It takes the technology of all die-cast aluminum, which is secure and nice in appearance. It's very lightweight and each module connected by special connecting constitution to achieve fast assembly. Fi series are suitably applied in vocal concert, Live show, TV station, Meeting, nightclubs, DISCO and supermarket for displaying and advertising use.
Product Features:
1. All die-cast aluminum, secure and nice in constitution.
2. Dust proof, IP 43.
3. Auto locking system, super easy to assemble and disassemble.
4. Fan-less design with great structural heat dissipation function, achieving noise-free
5. High refresh Rate, flicker-free[no scan lines] *even under HD cameras, superior images are available for live events.
6. Large viewing angle, the panel viewing angle is up to 140, the vertical angle could reach 140, the image won't be out of shape and color cast between the rang.
7. Could be exact connected and easy to install and dismount.
Advantages:
1. Fanless design.
2. Competely black LED with high contrast.
3. HD video performance.
4. Die-casting aluminum, nice heat dissipation.
5. Individually removable and replaceable.
Item |
Fi3.75 |
Fi 4 |
Fi 4.615 |
Fi 5 |
Fi 6 |
Pixel Pitch |
3.75mm |
4 mm |
4.615 mm |
5 mm |
6 mm |
Brightness |
900nit |
900-1600nit |
900nit |
900-1900nit |
650-1900nit |
Refresh Rate |
288 0 Hz |
1 92 0 Hz |
1 92 0 Hz |
1 92 0 Hz |
1 92 0 Hz |
P ixel Matrix |
128x128 dot |
120x120 dot |
104x104 dot |
96x96 dot |
80x 80 dot |
Pixel density (dot/sqm) |
71111 |
62500 |
46656 |
40000 |
27777 |
LED Type |
1 R 1 G 1 B
S MD 2121 |
1 R 1 G 1 B
SMD 2724 |
1 R 1 G 1 B
SMD 3528 |
Best Viewing distance |
4m |
4m |
5m |
5m |
6m |
Max . Power consumption |
100W/pcs |
120 W/pcs |
90 W/pcs |
90 W/pcs |
70 W/pcs |
Ave . Power consumption |
60 W/pcs |
65 W/pcs |
50 W/pcs |
50 W/pcs |
40 W/pcs |
Panel Size |
480x480x80mm |
Viewing angle |
1 4 0° X 1 4 0° |
Gray Scale |
12bit |
Color Temperature |
8000K±500 |
Weight |
8.5kg/pcs |
Working Voltage |
AC 220V±10% |
E nvironment |
T emperature -10~ 50°C, humidity 10-90%RH |
Control system |
PC based, dynamic capture & mapping. |
Reframe Rate |
≥60 Hz |
Protection Level |
IP43 |
Operating Life |
> 50,000 hours |
Certificate |
CE
|
