Dgx P25 Outdoor LED Display-03

Name: Dgx P25 Outdoor LED Display-03
Brand: yourledlight.com
SKU: 651167035
Availability: InStock
Rating: 4.9 (53 reviews)

Price:	US $ 500-1000/Square Meter
Trade Terms:	FOB,others
Min Order:	10/Square Meter
Pay Type:	T/T

Contact Supplier

Shenzhen DGX Technology Co., Ltd.

Showroom Product Company Profile

Prod Model:	DGX-OP25
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Power Consumption:	600W/Sqm
Display Type:	LED Video Display
Tube Chip Color:	Full Color
IP Rating:	IP65
Pixel Configuration:	2R, 1G, 1B
Pixel Pitch:	25mm
Display Function:	Video Display
Scanning Mode:	Static Scan
Certification:	RoHS
Pixel Density:	1600 dot / m²
Average Power Consumption:	600W / m²

Product Description

PH25 outdoor full-color LED display-03 parameter Pixel pitch: 25mm Pixel density: 1600DOT/m2 Modules size: 200mm*200mm Pixel configuration: 2R 1G 1B Brightness: >=4000 CD/m2 Visible angle: H110 V70 deg Drive method: Static Resolution: 8*8 DOT LED enveloping: DIP 546 Cabinet size: 1200*1000*150 mm Quantity/cabinet: 5*6=30/PCS Cabinet Weight: 48kg(approximate) Cabinet resolution: 1920DOT Optional viewing distance: 15~300 m Work voltage: 5 V Refresh rate: >300 Hz Display color: 16.7M Power consumption: Max: 450 Average: 150 W/m2

1	Module Size	200mm * 200mm
2	Module resolution	8*8 pixels
3	Density	1600 dot / M2
4	Power consumption	≤1000w/m2
5	Display Luminance	≥5000cd/m2
6	Drive Mode constant	static
7	Viewing Angle	Horizontal :140°,vertical : 140°
8	Viewing Distance	From 5 meters to 60 meters
9	Grey Scale	red\green\blue ,256 gray scales respectively
10	Color	16.7 million
11	Change frame	≥100HZ
12	Scanning rate	180HZ
13	Screen life	50000-80000 hours
14	Screen MTBF	100000 hours
15	Blind rate	≤0.0002
16	Working Voltage	AC220V±10%,50Hz
17	Control distance	≤100 meter with cat5 cable(MMF 500 m,SMF 20 000m )
18	System working Environment temperature	-55 °C~ +85°C
19	System working environment Humidity	10%_95%RH
20	Continuous working time	24hours /day
21	Color temperature	6000K±500
22	Information source	Many kinds of signal access ,can input TV signal ,DVD signal ,Computer signal,internet and other
23	Control graphics technology	Intellective control technology, test-itself technology ,correct technology.
24	Multimedia control technology	Abundant multimedia video picture ,characters manifest function ,and switch quickly function
25	Maintenance	Pixel by pixel
26	Configuration	Screen composed of the cabinets ,cabinets composed of the modules
27	Maintenance manner	Reservation position is 45cm
28	Switch manner	Computer control switch automatically
29	Remote management (extra charge,optional,default is cable control))	Remote control display system and operate
