Time Saving:
Labor Saving
Transport Cost Saving:
Matrial Saving
Tube Chip Color:
Full Color
IP Rating:
IP65
Pixel Configuration:
1R, 1G, 1B
Display Function:
Video Display
Average Power Consumption:
600W / m²
Scanning Mode:
1/4 Scan
Display Type:
LED Video Display
Application:
Stage Performance
Certification:
CCC
Pixel Pitch:
7.8mm
Pixel Density:
16384
Product Description
MainTechnical Parameters of Magic Stage Series MG5 commercial p7.8 led display in electronic signs 12 years manufacture
Pixel pitch(mm)
6.25
7.8
Pixel density(dot/m²)
25600
16384
LED Encapsulation
3528
3535
Weight(kg)
5.8
6
Average consumption(w/m²)
480
480
Brightness(cd/m²)
6000
6000
Module Resolution(dot)
80*80
64*64
Scanning mode
1/5Dynamic constant current
1/4 Dynamic constant current
Minimum viewing distance(m)
6
8
Configuration
1R1G1B
1R1G1B
Viewing angle(H/V)
160°/120°
160°/120°
Display color
4096 grade/ 64G
4096 grade/ 64G
Working voltage
AC 220V/ 50Hz
Brightness adjustment
Brightness of R.G. B color can adjustable by software
Brightness of R.G. B color can adjustable by software
Refresh frequency
<3840
<3840
Working environment temperature
-20~50ºC
-20~50ºC
Malfunction dote rate
<0.00003
<0.00003
Average no failure time
>10000hour
>10000hour
Life span
>100000hour
>100000hour
Cabinet material
polymer nanomaterial
polymer nanomaterial
Arc installation angle
15°inner or outer arc
15°inner or outer arc
Communication method
HSYV
HSYV
Control system
NOVA
NOVA
Certification
FCC,Rosh,CE, CCC, TUV,BV
FCC,Rosh,CE, CCC, TUV,BV
HUNAN XINYASHENG TECHNOLOGY& DEVELOPMENT Co., Ltd (short for YES TECH) was established in 2001. It is a professional LED application products manufacturer, composed by R&D, production and sales, etc. Our head office locates in at No. 108 Qingzhuhu Road, Kaifu District, and Changsha City, Hunan Province. And branch in Shenzhen, Singapore; Branch sales office in Shanghai and Changchun.
YES TECH has been exploring the LED technology all these years. We are dedicated to put our research result into practice and achieve industrialization,
Marketization and Large-scale production. Through years' research, YESTECH has developed several versions of LED products and system integration software, and obtained patent for that. Moreover, we established "research foundation of LED screen and LED lighting technology" with Universities. Until now, we have two main application products: LED display Screen and LED lighting. We are also trying to extend other application fields.
Relying on advanced management mode, first-class technology, excellent products and perfect service, YES TECH products have widely covered the government, education, finance, media, transportation, electric power, military, commercial, sports field, and built an international LED industry platform. By now, YES TECH has implemented tens of thousands of LED display projects around the world and has brought the glaring vision and built friendly strategic partner relationship with more than 60 countries and regions, it is including France, Germany, Portugal, Russian, Canada, Egypt, Korean, Singapore, Indonesia, Mexico, Argentina, etc.
YES TECH LED application product is the leader of quality and confidence in LED industry. Yes-Tech passed the China Compulsory Certification (CCC), ISO9001 quality management system certification and CE certification; Meanwhile we has gained the national scientific and technological innovation-oriented SME and the Key Recommended Enterprise for New Products, AAA level member company of quality, State Innovative Small and Medium-sized Enterprise for Sci-Tech
In the future, YES TECH would adhere to the enterprise spirit-"Quality is the life of the enterprise; Credit is the spirit of enterprise; Development, exploration, practice, innovation". Forge LED wonderful "horizon cup", and lead the LED green lighting industry striding forward, and finally achieve an ideal road of " harmonious development between Human being and nature by using of science and technology".
