LED Encapsulation:
SMD3535
Waterproof IP:
IP65
Cabinet Size:
500X1000mm/500X500mm
Cabinet Material:
Aluminum Profile
Tube Chip Color:
Full Color
IP Rating:
IP65
Pixel Configuration:
1R, 1G, 1B
Display Function:
Video Display
Average Power Consumption:
300W / m²
Display Type:
LED Video Display
Certification:
RoHS
Pixel Pitch:
8.928mm
Pixel Density:
12546dots/Sq.M
Scanning Mode:
1/7scan
Application:
Advertising,Stage Performance,Rental
Product Description
P8.928 full color led curtain for indoor or outdoor use with angle adjuster system to be certain arc shaped,high brightness and good light transmittance
1.SMD led encapsulation confirm wide view angle and slim thickness
2. High resolution,high refresh rate, no stroboflash, eyes friendly
3. Good waterproof IP65 for outdoor,long life span,more than 100000Hours
4.With aluminum cabinet,ensure the lightweight, easy and quick to assemble and disassemble,can be moved by hands
5.Good light transmittance,good heat dissipation and low power consumption
6. Can be assembled to be certain abnormal shapes,like "S" with angle adjust system,to meet different request
7. Cabinet size can be 500x500mm or 500x1000mm,also can be mixed for these two panel size for a same screen
8. Widely used for stage, concert ,show, banquet, wedding ,party background etc, also can be used for led dance floor
Please see more pictures for reference
P8.928 full Color LED Screen/Curtain Specification
Pixel pitch
8.928mm
Pixel Configuration
1R1G1B
LED component
SMD3535
Size of module
250mm*250mm
Resolution of module
28x28
Size of cabinet
500mm*1000mm x 70mm
Resolution of cabinet
56x112
Material of Cabinet
Aluminum
Weight of Cabinet
13KGS
Brightness
>4500cd/
Density
12546dots/
Best viewing angle
140 /140
Pixel Configuration
1R1G1B
Best viewing distance
8-100M
Maximum power consumption
700W/
Average power consumption
350W/
Driving method
1/7 scan
Control method
Synchronization
Gray scale
65536
Colors
256*256*256
Color temperature
3200-9300k
Uniformity
97%
Working voltage
AC220V/110V±10%
Working temperature
-20ºC~+50ºC±10%
Working humidity
10% ~ 90%
MTBF
10,000 hours
Frame frequence
50/60Hz
Refresh frequence
>1920Hz
IP grade
IP65
Life Span
100,000 hours
Data transafer method
RJ45
Pratical standard
CCC TUV-CE ETL etc.
Effectivce Communication Distance(without relay)
Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M; Single-mode optic fiber: 10KM
Accepting signal with video processor
PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.
Systems operating platform
WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
