North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Average Power Consumption:
350W/M2
Life Span:
>100, 000hours
Mtbf:
>10, 000hours
Delivery Time:
3-12working Days
Product:
P5 Indoor Full Color
Module Size:
320*160mm
Brightness:
2500CD/M2
Module Dots:
64*32
Usage:
P5full Color LED Display
Life Span Time:
100,000 Hours
Tube Chip Color:
Full Color
Display Function:
Video Display
Pixel Pitch:
5mm
Pixel Configuration:
1R,1G,1B
Pixel Density:
40,000 dots / m²
Scanning Mode:
1/8 Scan
System Operating Platform:
WIN XP
Display Type:
LED Video Display
Application:
Advertising
IP Rating:
IP43
Certification:
CCC
Product Description
Usage;
LED display is widely used in finances, post offices, telecom, commerce, hospitals, stadiums, shop, plaza, concert, fashion shows, exhibitions and so on.
Features and advantages; 1. Your inquiry related to our products or price will be replied in 24hours 2. OEM&ODM price, ex-work price, factory price, FOB price, CIF price. 3. Products of various specs and models may be ordered at your requirement. 4. Our engineers are free to help installing and adjusting display. 5. Fast installation structure and hanging up, super thin cabinet and super light weight.
Our factory professionally manufacture follow products, 1) Single color LED display, dual color LED display, and full color LED display. 2) Indoor LED display semi-outdoor LED display and outdoor LED display. 3) LED moving sign, LED message sign, LED sign, programmable LED moving message sign board, variable message signs, electronic message sign, LED scrolling message signs, LED text display. 4) LED display screen, LED display board, LED display module, LED display cabinet. 5) LED video display, LED advertising display, truck mobile LED display, rental LED display, stadium LED display, concert LED display, and stage LED display. 6) Wireless LED display board, computer controlled LED display.
Warm Tip There is DIP, SMD, and Dotmatrix LED display for customer choosing. LED display styles: P4, P4.75, P5, P6, P7.62, P8, P10, P12, P12.5, P14, P16, P20, P25, P31.5,
Numbers
Technical indexes
Specification
1
Pixel pitch
5mm
2
Module size
320mm×160mm
3
Module resolution
64×32
4
Module density
40,000dots/sqm
5
Pixel configuration
RGB,3 in 1
6
Red wavelength
625±2nm
7
Green wavelength
525±2nm
8
Blue wavelength
470±2nm
9
Colors
16777216
10
Best viewing distance
5m---150m
11
Horizontal viewing angle
140°
12
Vertical viewing angle
70°
13
Maximum power consumption
1000W/sqm
14
Average power consumption
400W/sqm
15
Brightness
10,000cd/sqm,adjustable
16
Gray scale
16bits of per color
17
Color temperature
12,000K
18
Driving method
1/8scanning
19
Frame frequency
60Hz
20
Refresh frequency
300 Hz
21
Working voltage
AC220V/110V±10%
22
IP grade
IP20-45
23
Working temperature
-20°C~80°C
24
MTBF
More than 10,000 hours
25
Life span
More than 100,000hours
Shenzhen Foxgolden Technology Limited, is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R&D, production, project, capital and marketing.
As a professional and market-oriented LED display manufacturer, FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness, but also makes breakthrough progresses on special usages. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and overseas market.
Foxgolden provides a full series of LED display products involving various single and dual color, text & image display; Indoor single & dual color, full color screen; Outdoor single & dual color, full color display; DOT matrix module display; Traffic applied product; And series of indoor & outdoor module.
Our company has provided our indoor & outdoor displays for various kinds of locations and events throughout the world. With high quality and perfect after-sale services, our professional products and solutions are highly complimented by the users, and we also earned high credibility from them.
With cultivation for high-quality production management team and project team, high quality products and local maintenance service; We achieved zero complaint in product quality for 3 constant years. That's why Foxgolden has received comprehensive attentions from LED industrial experts these years.
