Prod Model: |
MHLED 60DA |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Output: |
DC 24-36V |
Switch Power Supply: |
Built-in and Auto Switching |
Control Panel: |
Digital LCD Display |
Connector: |
3 or 5-Pinxlr (in and out) |
No.of LED: |
1* 60W White |
Cooling: |
Entire Casing as Heat Sink Plus Noiseless Fans |
Flicker Free: |
Refresh Rate >1000 Hz |
Key Point: |
Temperature-Protected Handly |
Usage: |
Theatres, Stage , Robust Housing |
Lamp Luminous Efficiency(Lm/W): |
99% |
IP Rating: |
IP20 |
Strobe: |
Combined Type Double Strobe |
Certification: |
SGS |
Light Source: |
LED |
Control Channel: |
16CH |
Control Mode: |
DMX512, Master /Slave Mode, Sound, Auto |
Voltage: |
90-245VAC 50/60Hz |
Product Description
Control: DMX-512 12-14 channels
Color wheel: 7 colors + white, spilt colors, rainbow effect
Gobo wheel: 8 static gobos + white, rainbow effect, gobo shake
Gobo wheel: 5metal+ white +1 glass installed +Rainbow effect Gobo shake
Effect wheel: 3-facet prism (adjustable rotating speed and direction)
Shutter: 0-20Hz
Dimmer: Variable electronic dimmer (0-100%)
Focus: Variable motorized focus
Master/Slave activated by sound at pre-programmed function
Pan: 540° /360° /180° , 8/16 bit movement resolution, automatic correction
Tilt: 270° /180° /90° , 8/16 bit movement resolution, automatic correction
Power supply: AC 110V-240V 60/50Hz
Power consumption: 115W
Light source: 60W white color LED
Beam angle: 15°
Brightness: 38, 500 @ 1m
N. W.: 7.3Kg/G. W.: 8.5Kg
MEAS: 36CMx34CMx32CM
Housing Material |
Aluminum |
Housing Color |
Black/White |
Aperture Cover |
Aluminum |
Certification: |
CE,EMC, LVD, RoHs |
Electronic Dimmer: |
10-100% linear dimmer |
Electronic Strobe: |
1-30 flashes/second |
LED Life Time |
80000-100,000 hours |
Power Consumption |
90W |
Light Projecting Distance |
5-200M |
IP Rating |
Indoor |
Operating Temperature |
-20ºC-+45 ºC |
Power In: |
Fixed |
CRI (Ra>): |
95 |
Accessories: |
Power cable,power con cable,omega clamp, XLR DMX Signal cable,Safety Rope |
9. Thermal: |
Maximum ambient temperature: 40° |
Maximum housing temperature: 60° |
|
|
Packaging & Delivery |
|
Packaging Detail: |
Standard Export packing by carton or OEM package |
Delivery Detail: |
2-5 days for sample , 5-12 days for mass quantity order |
Shipping |
By DHL, UPS, FedEx, EMS or TNT, boat ,Air. |
Guarantee |
we guarantee that all the product have been shipped after the testing , if there any damage caused in transit , we can not control the entire process , if so , we are happy to communicate with you friendly solution. |
Items have 2 YEAR warranty. ( Except lamp-house). |
