Prod Model: |
CN-DL01-PW15-H6/CN-DL01-WW15-H6 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Mid East,Eastern Asia,Western Europe |
Size:: |
6 inch |
Assembly Diameter: |
168 mm |
Base Material: |
Metal |
Cover Material: |
Plastic |
Shape: |
Round |
Light Source: |
LED |
Certification: |
CE |
Voltage: |
96-265V AC |
Beam Angle: |
120 |
Product Description
LED down light
1. Model No. CN-DL01-PW15-H6/CN-DL01-WW15-H6
2. Input Voltage: AC96-265V/DC12V
3. Frequency: 50/60Hz
4. Input Power: 15W
5. Luminous Flux: 1050-1200lm
6. Rendering Index: >75
7. Beam angle: 120 deg
8. Power factor: 0.9
9. Working Temperature: -30-+50
10. Housing material: Aluminum &PC
11. Assembly Diameter: 168mm
12. Color Temperature: Warm white 2800-3000K; Pure white 5500-6000K
13. Certificate: CE & RoHS
[Products features]
1. Good optical design: Radiating a soft, uniform light with improved even diffusion with no circular appearance.
2. Light casing with high quality aluminum alloy materials is beautiful and simple;
3. No UV, no radiation and environmental protection;
4. In general the life span is more than 35, 000 hours(Light is less than 8 hours a day).
[Application]
Widely used in super market, hotel, coffee house, hank, meeting room, exhibition hall and living house.
The advantages of our LED down light
1. LED down light housing are adapted high quality aluminum material with very good heat elimination. Indoor use only.
2. Imported high brightness SMD3528 (3 chips) as the light source. The light attenuation is below 5% within 5000 hours.
3. The LED down light cover adopts high transmittance milk PC material. The milky cover can reach the 85% light transmittance
4. The driver is external constant current power design to ensure the stability of the fixture.
5. Working voltage can be selected: 12V DC, 96-265V AC.
6. Single color of pure white and warm white for option or other colors.
Remarks: (LED down light)
1. Only use for indoor light
2. Installed in the environment of waterproof and good heat dissipation
3. Avoid touching the heat dissipation cover when the product is working
4. Avoid glaring the illuminant light when the product is working.
Trade Terms:
1. Lead time: Sample order 5-7 days, Formal order: 15-20 days
2. Payment: T/T and Western Union
3. Shipping: By Express, By Air or By Sea
4. Logo: According to your requirement
5. Discounts are offered based on order quantities
6. Minimum Quantity: 100PCS
Model No. |
Power |
Size |
LED Quantity |
Assembly Diameter |
Voltage |
Color temperature |
Luminous flux |
CN-DL01-WW03-H2 |
3W |
2.5” |
20pcs
SMD3528 (3chips) |
80mm |
AC96-265V |
2800-3000K (Warm white) |
210-270lm |
CN-DL01-PW03-H2 |
5500-6000K
(Pure white) |
CN-DL01-WW08-H3 |
8W |
3” |
35pcs
SMD3528 (3chips) |
90mm |
AC96-265V |
2800-3000K (Warm white) |
560-720lm |
CN-DL01-PW08-H3 |
5500-6000K
(Pure white) |
CN-DL01-WW10-H4 |
10W |
4” |
48pcs
SMD3528 (3chips) |
120mm |
AC96-265V |
2800-3000K (Warm white) |
700-900lm |
CN-DL01-PW10-H4 |
5500-6000K
(Pure white) |
CN-DL01-WW12-H5 |
12W |
5” |
54pcs
SMD3528 (3chips) |
158mm |
AC96-265V |
2800-3000K (Warm white) |
840-1080lm |
CN-DL01-PW12-H5 |
5500-6000K
(Pure white) |
CN-DL01-WW15-H2 |
15W |
6” |
70pcs
SMD3528 (3chips) |
168mm |
AC96-265V |
2800-3000K (Warm white) |
1050-1350lm |
CN-DL01-PW15-H2 |
5500-6000K
(Pure white) |
CN-DL01-WW15-H2 |
20W |
8” |
96pcs
SMD3528 (3chips) |
210mm |
AC96-265V |
2800-3000K (Warm white) |
1400-1800lm |
CN-DL01-PW15-H2 |
5500-6000K
(Pure white) |
Beam angle: 120 degree |
Manufacture Experience: 15years |
Certificate: CE/ROHS |
Size: |
Life: 35, 000Hours;
Power Factor: 0.85 |
Warranty: 2 Years |
Color rendering index: 0.8 |
Material: Aluminum+ PC |
Trade Terms: FOB/EWX/CIF |
Reflector efficiency: 90% |
NON-dimmable |
Delivery: 3-20Days According quantity |
|
