Feature:
1. 5 pixels (each LED is a pixel), individually controllable
2. 10W RGBW 4in1 LEDs, RGBW Infinite color mixing
3. stable performance, long life
4. Efficient low noise fan cooling system
5. Factory supply and lower price
Specification:
Light Source: 5pcs*10W LED (RGBW 4 IN 1)
Function: Outstanding beam effects
Lifespan: 50000hrs
Color: RGBW infinite color mixing, can mix to more than 16.7million kinds of color
Control Mode: DMX 512, Master/Slave, stand-alone, Sound activated
Channel: 14CH
Beam Angle: 6°
420LUX(R), 492LUX(G), 610LUX(B) and 1070LUX(W)@7M
Pan: 540°
Tilt: 270°
Built-in power supply
Built-in 3-pin XLR serial data connection.
Control board with 4-digit display.
Shutter/Strobe: 1-100% linear adjustable
Dimming: 1-100% linear adjustable
IP20
Size: 460x370x380mm
N.W: 7.5KG G.W.: 8.5KG
DMX Channel:
| CH MODE | 1 | 2 | 3 | 4 | 5 | 6 | 7 |
| 14CH | pan | Pan Fine | Tilt | Tilt fine | Pan/Tilt speed | Dimmer | Strobe |
| 8 | 9 | 10 | 11 | 12 | 13 | 14 |
| Red | Green | Blue | White | Built-in program | Speed of program | Reset
|
