Prod Model: |
AN-36 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
LED Panel Size: |
595*595mm |
LED Chip: |
SMD2835 |
Cct: |
2700-6500k |
Input Voltage: |
AC100-240V |
Light Source: |
LED |
Appearance: |
Square |
Type: |
Ceiling |
Emitting Color: |
White |
Certification: |
CCC |
Housing Material: |
Acrylic |
Voltage: |
100-240V |
Dimmable: |
With Dimmable |
Base Material: |
Aluminum |
Beam Angle: |
180 |
Product Description
36W SMD2835 LED panel lighting
LED panel lamp specification:
Size: 595*595mm
Input Voltage: AC100-240V
Power: 36W
Power Factor(PF): >0.95
Power Efficiency: 85%
36W 595*595mm led thin light box panel
Light source: SMD-2835
LED chips: Epister
LED Qty: 180PCS
Ultra slim LED lighting panel
Colour temp: 2700-6500k
CRI: >Ra70
Luminous flux: >2800lm
Angle: 180degree
595*595mm LED ultra slim Light Box
Working Temp: <40centigrade
Life-time: 30000H
Material: Alum+PMMA
Finish: Silver
IP Rating: IP44
Features of LED ceiling panel lights:
1. Unique and super-slim designation. The thickest part of the product is only 8.5 mm
2. Wide range of voltage which can be used all over the world. Constant current all through 85 V-264 VAC voltage range ensures protect the lifespan and brightness from voltage fluctuations.
3. Environmental-friendly: No mercury, no pollution. Assembly components can be very easily dismantled and outfit. Other people can recycle them without the help of manufacturers.
4. Safe and reliable. The driver isolates the high voltage and low voltage which ensure safety
5. More than 30000 hour's lifespan can save a lot of maintenance expense
6. No ultraviolet (UV) and infrared (IR) radiation. Human won't grow flecks even under the light long time.
7. High range of color temperature, almost all the color temperatures are available.
8. The light is very soft.
Application place
This LED Panel lighting is widely used in shopping mall, exclusiue shop, restaurant, 4S shop, factory, hospital and amusemet place.
Size:595×595
Input Voltage: AC100-240V
Power: 36W
Power Factor(PF):>0.95
Power Efficiency: 85%
Light source:SMD-2835
LED chips: Epister
LED Qty:180pcs |
Colour temp : 2700-6500k
CRI:>Ra70
Luminous flux:>2800lm
Angle: 180degree
Working Temp: <45C
Life-time:30000H
Material: Alum+PMMA
Finish:Silver
IP Rating:IP20 |
