Prod Model: |
CZPL36013 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Size: |
1200X230X68mm |
LED Source: |
SMD 2835 |
PF: |
>0.9 |
Ra: |
>80 |
Efficiency: |
85-95lm/W |
Cct: |
3000k/4000k/6000k |
Color Of Frame: |
White/Silver |
Dimming Method: |
Triac |
Dimming Range: |
0-100% |
Package: |
2PCS/CTN,126X25X32cm/CTN, G.W:15kg/CTN |
Light Source: |
LED |
Emitting Color: |
White |
Type: |
Ceiling |
Certification: |
ISO9001 |
Voltage: |
100-240V |
Housing Material: |
Aluminium, PC |
Dimmable: |
Dimmable Available |
Appearance: |
Quadrangle |
Beam Angle: |
120 Degrees |
Product Description
1. Features:
1.) High luminous efficiency up to 85-95lm/w,
2.) Soft and uniform light output,
3.) Be compatible with leading-edge dimmer.
4.) DALI&silicon controlled Dimmer version is aslo available
2. Specification:
P/N: | CZPL36013 | CZPL48013 |
Power Consumpion: | 36W | 36W |
Input Voltage: | 100-240VAC | 100-240VAC |
PFC: | ≥0.9 |
C.C.T.: | 3000K+4000K+6000K ALL Available |
Luminous Flux: | 3060-3420lm | 4080-4560lm |
Ra: | ≥80 | ≥80 |
Size: | 1200X230X68mm | 1200X230X68mm |
N.W | 4.65kg | 4.65kg |
Lifetime | 40,000hrs | 40,000hrs |
3. Certifications:
CE and RoHS
4. Delivery time:
3-5 work days for sample order,
10-15 work days for general orders.
5. Warranty:
2 years warranty in default, can be extended as well.
6. Options:
1.) DALI&silicon controlled Dimmer version is aslo available.
7. Trade terms and payment:
Exw basis, 30% deposit, T/T, L/C, Paypal, Moneygram, Western Union acceptable.
8. Why Odidea?
1.) Large capacity to handle bulky orders,
2.) Genuine high quality products,
3.) Punctual delivery,
4.) Flexible and adaptable,
5.) Immediate response to requirements with efficient supply chain and strong R&D expertise.
