Lamp Source:
Yodn Msd 15r 300W/ Osram Siruis Hri 330W
IP Rating:
IP20
Strobe:
Combined Type Double Strobe
Control Mode:
Dmx Signal Control
Certification:
RoHS
Control Channel:
16CH
Voltage:
100V-240V
Light Source:
Osram Ostar 19X15W 4in1 RGBW
Material:
ABS
Emitting Color:
RGBW
Product Description
15R SPOT PRO FEATURES
Brighter: (New 330W Lamp Source Brings Incomparable Pure Brightness) Small size but stronger: (Comparable Output Of 1500W Fixtures, but 1/5 Power Consumption and 1/3 size Only 23kg, 41*37*75cm) Best color system: (CMY color mixing effect and 6 dichroic colors, YL optic system) Best gobo system: (2 gobo wheels: 14 static gobos and 8 rotating replaceable gobos) Most Funtional: (Zoom, Iris, Prism, Focus, Frost Filter, Shutter, with full Moving Heads Spot/Wash functions)
TECHNICAL PARAMETERS
POWER SUPPLIE Input power: AC110-240V 50/60 Hz LAMP SOURCE Lamp: Yodn MSD R17 350W, 1, 500hr, 8000k(Optional Osram Siruis HRI 330W) Power Consumption: 350W OPTICS Lens: Anti-reflective coated lens YiLong optic system Output Lux: 10, 500lux at 20 meters COLOR SYSTEM Colors: Basic color wheel with 6 dichroic mirrors, plus white, two direction rainbow effect. CMY Variable Color Mixing for Infinite Color Possibilities GOBO SYSTEM 8 rotating gobos plus open, all gobos can be easily replaceable and gobo indexing Static gobo wheel with 14 indexing gobos plus open, gobo shaking in different speed EFFECTS SECTION Prism and prism rotating, with 16 prism macros Linear dimmer in precise speed from 0% ~ 100% Stepless frost, 0%-100% linear change frost Motorized focus Iris from 5%~100% with pulse iris effect. Zoom: 9° ~27° Linear zoom Strobe/shutter: High speed shutter, 0-13 Hz or random strobe CONTROL AND PROGRAMMING DMX Channels: 3 DMX Modes-21/23/34 Channels DMX Control: 3-pin&5-pin DMX Control board with LCD graphic display BODY Remote controller lamp's switch function, display light and lamp's using time Structure: Heat-proof plastic+module pressing alloy materials MOVING BODY Pan and tilt movement: 8 and 16 bit resolution For smooth and precise motion Movement: Pan: 360° /540° Optional, Tilt: 270° Speed of pan/tilt movement adjustable Scan position memory, auto reposition after unexpected movement WEIGHT&SIZE Weight: 23kgs Dimensions: 409*419*541mm
ST 23CH
BA 21CH
EX 34CH
1
Pan
1
Pan
1
Pan
2
Pan Fine
2
Pan Fine
3
Tilt
2
Tilt
3
Tilt
4
Tilt Fine
4
Tilt Fine
5
Color Wheel
3
Color Wheel
5
Color Wheel
6
Color Wheel Fine
6
Cyan
4
Cyan
7
Cyan
8
Cyan Fine
7
Magenta
5
Magenta
9
Magenta
10
Magenta Fine
8
Yellow
6
Yellow
11
Yellow
12
Yellow Fine
9
Rotating Gobo
7
Rotating Gobo
13
Rotating Gobo
10
Rotating Gobo Rotation
8
Rotating Gobo Rotation
14
Rotating gobo index
15
Rotating Gobo Fine
11
Fixed Gobo
9
Fixed Gobo
16
Fixed Gobo
17
Fixed Gobo Fine
12
3 Facet Prism and Macro
10
3 Facet Prism and Macro
18
3 Facet Prism and Macro
13
Rotating Prism
11
Rotating Prism
19
Rotating Prism
20
Rotating Prism Indexing Fine
14
Focus
12
Focus
21
Focus
22
Focus Fine
15
Zoom
13
Zoom
23
Zoom
24
Zoom Fine
16
Shutter
14
Shutter
25
Shutter
17
Dimmer
15
Dimmer
26
Dimmer
27
Dimmer Fine
18
Iris
16
Iris
28
Iris
29
Iris Fine
19
Frost
17
Frost
30
Frost
20
Speed of CMY
18
Speed of CMY
31
Speed of CMY
21
Speed of Pan/Tilt
19
Speed of Pan/Tilt
32
Speed of Pan/Tilt
22
Color Macro-CMY Color Wheel
20
Color Macro-CMY Color Wheel
33
Color Macro-CMY Color Wheel
23
Lam on&off Reset
21
Lam on&off Reset
34
Lam on&off Reset
Guangzhou Lees Electronics Co., Limited professional in stage lighting electronic and equipment, especially in beam moving head lighting. Have a great team of programming-makers, superb technicists, experienced salers, and advanced stuffs.
After one year preparation, we researched one new moving head lighting. 300W beam moving head light. In the beginning of beam light hot year, Many customers all over the world are looking for beam light factory in China. Especially crazy for similar products with Claypaky, Martin, Robe brand.
Continuing the exploration and innovation, Lees launched the 5R Sharpy Beam, 2R Beam, 15R Beam and 15R Spot&beam in succession.
Looking forward to your contact. And Let's talk about beam light together!
