Prod Model: |
SZ-CNEC |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Power Consumption: |
230 V, 50 Hz 350 Va |
IP Rating: |
IP65 |
Certification: |
SGS |
Control Mode: |
16/20 of The International Standard DMX512 Channel |
Control Channel: |
16/20CH |
Voltage: |
AC100-240 - V, 50/60 Hz |
Product Description
1. The light bulb, OSRAM 7 r (10000 k color temperature, 2000 hours)
2. Power consumption: 230 v, 50 hz 350 va
3. The optical device: Three slices of lenticular lens group, zoom 0 ° And 3.9 °
4. Electronic focus: 20 meters, 70000 lux
5.2 channel modes: 16/20 of the international standard DMX512 channel
6. Horizontal: 540 ° (16 bit several scans)
7. Vertical scanning: 280 ° (16 bit several scans)
8. Color plate: 14 call waiting type color + white light, with two-way rotation of rainbow effect
Pattern plate at 9.: Eight prism, can be positive and negative direction of rotation, and have a prism positioning function, pluggable type color piece, 14 kinds of color + white light
10. Prism plate: Eight prism, can be positive and negative direction of rotation, and have the function of prism location
11. A stroboscopic: Double pole stroboscopic frequency highest can 13 times per second, and can choose random stroboscopic and pulse frequency flash
12. The dimming: 0-100% linear dimming
13. The atomization: 0-100% linear atomization and beautiful blue and white liquid crystal display, the shuttle rounds of selection menu, convenient and quick
14. Optional: Electronic ballasts products lighter weight, better brightness, lamp is more stable, more environmental protection, more energy efficient bulb remote control switch
15. Optional: Switch power supply AC100-240 - v, 50/60 hz
