Ballast:
E-Ballast
Display:
LCD Display
Color:
14 Colors + Open
Gobo:
17 Gobos+Open
Lens:
3-Lens Group (Glass)
Material:
Aluminum Alloy
Emitting Color:
Changeable
Strobe:
Combined Type Double Strobe
Control Mode:
Dmx Signal Control
IP Rating:
IP20
Certification:
RoHS
Light Source:
Philips Msd Platinum 5r
Control Channel:
16CH or 20CH
Voltage:
100~240AC
Product Description
2015 Hot 200W Sharpy 5r Moving Head Light
Youtube Beam Demo
https://youtu.be/9ILMNZMzj-Q
https://youtu.be/-UZwem5vDlI
24 Prism Effect Beam Effect Tech Spec: Input voltage: 100-240V, 50/60Hz; Machine Power: 350W; Light source: Philips MSD Platinum 5R with 189W; Color temperature: 8000K; Average lifetime: 2000 hours; Color system: One color wheel with 14 different inner color fitters plus white. Color fitters can be changed; Gobo system: One fixed Gobo wheel with 17different inner gobos with shaking function; Lens: 3PCS PHILIPS lens group with electronics zooming 0~3.8 degree Strobe: Support mechanical strobe & adjustable speed stobe effect; Prism: 8-faced prism with rotation; Frost: 0%~100% linear frost; Beam angle: 0° ~8 ° ; Control mode: DMX512 signal control with 3 pin interfaces & LCD display with 16CH; Ballast: Electronics ballast and AC/DC power supply. Power factor is more than 99%, THD<20%; Head movement: Horizontal: 540° , 8bit/16bit precision scanning with auto position correction; Vertical: 270° , 8bit/16bit precision scanning with auto position correction; Environment temperature: -15° C ~45° C; Shell material: Aluminum alloy composites plastic, IP20; Package size: 523*337*511mm; Gross weight: 19KG Applicaiton: UP-B200M moving head light is a best choice for stage lighting of TV Studio, theater, opera house, Auditorium, fashion T stage, vocal concert, club, disco at present with good quality light and small size. It is brighter than beam 300. It is 100% high copy Claypaky.
Production
CH8
CH8
Frost
CH9
CH9
Focus
CH10
CH10
Pan fine
CH11
CH11
Tilt
CH12
CH12
Tilt fine
CH13
CH13
Retain
CH14
CH14
Reset
CH15
CH15
Lamp on/off
CH16
CH16
Pan/tilt speed
CH17
Color wheel speed
CH18
Reset
CH19
Dimmer/prism/frost speed
CH20
Gobo wheel speed
