| Prod Model: |
AL-G200 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Lamp Source: |
189W Lamp |
| Control: |
Auto, Sound Actived, DMX, Master/Slave |
| Movement: |
540°/270° |
| Packing Size: |
420*480*580mm |
| Beam Angle: |
0-3.8 |
| Input: |
AC90-240V |
| Rotating Gobos: |
1 Gobo Wheel with 17 Fixed Fixed Gobo+Open |
| Colors: |
1 Color Wheel with 14 Fixed Colors+Open |
| Fixture Connection: |
3-Pin DMX in&out, Power in |
| Cooling: |
Quiet Fan Cooling |
| Light Source: |
Gas Discharge Bulb |
| IP Rating: |
IP44 |
| Strobe: |
Electronic Strobe |
| Control Mode: |
Dmx Signal Control |
| Certification: |
RoHS |
| Voltage: |
90V-240V |
| Control Channel: |
16/20 |
Product Description
200W 5r sharpy Moving Head Beam Light
AL-G200
Technical Parameters:
Lamp Source:
Yodn MSD189W R5/Philips
Color temperature: 8, 500K
Arerage Life: 2, 000Hrs
Input Voltage: AC90-240V 50/60Hz
Power Consumption: 250W
Control Method: DMX512, automatic and master/Slave
Channel: 16/20 CH
Display: 4-button LED digital/LCD display selectable
Optical: YiLong 3in1 optical group combination
Dimming: 0-100% linear adjustment
Strobe: Heat-proof plastic+module pressing alloy materials
Focus: ELectronic
Prism: Rotating 8-facet prism
Frost
Filter
Beam angle: 0-3.8 degree
Movement:
Pan: 540°
TilL: 270°
Pan/Tilt Resolution:
16bit
Gobos&Colors
Rotating Gobos: 1 gobo wheel with 17 fixed gobos+open
Colors: 1 color wheel with 14 fixed colors+open
Fixture Connection: 3-Pin DMX in&out, power in
Cooling: Quiet cooling fan
Packing Size:
Accessories: Power cable, signal cable
Omega safety cable and clamps
Product Size: 330*390*490mm
Packing Size: 420*480*580mm
N. W.: 17.00KGs
G W.: 19.5KGs
