Feature:
1. High power 330W philip Lamp
2. 14 Colors, 17 gobos, 8-facet rotation prism
3. Factory directly supply, low price
Technology Parametric:
1. Voltage: AC 100-240V, 50-60Hz
2. Ballast: Electronic ballasts/switch power supply
3. Lamp: Philips MSD Platinum 15R 330W, 1, 500 hr. 8000K
4. Color temperature: 8500K
5. Average Lamp Life: 2000H
6. Color: 14 color +blank color wheel
7. Gobo: 17 fixed gobo + blank gobo
8. Prism: Rotation 8-face prism, Bilateral rotation
9. Lens: High precision glass optical lens
10. Wash effect: Adjustable wash efffects angle
11. Focus: Linear adjustment
12. Dimmer: 0-100% linear adjustment
13. Movement: Pan/Tilt: X axis 540° Y axis 250° Automatically accurate postioning
14. Beam angle: Parallel beam angle 0-3.8°
15. Strobe: Double lens strobe (0.5-9times/second)
16. Control mode: Standard DMX 512, Automatic and Master/ slave mode
17. Channels: 16CHS/20CH
18. Packing size: 760X500X460mm
19. N. /G. W: 23kgs/26kg
DMX Channel:
| CHANNEL | CHANNEL MODE |
| 16CH | 20CH |
| 1 | COLOUR WHEEL | COLOUR WHEEL |
| 2 | STOP/STROBE | STOP/STROBE |
| 3 | DIMMER | DIMMER |
| 4 | STATIC GOBO CHANGE | STATIC GOBO CHANGE |
| 5 | PRISM INSERTION | PRISM INSERTION |
| 6 | PRISM ROTATION | PRISM ROTATION |
| 7 | EFFECTS MOVEMENT | EFFECTS MOVEMENT |
| 8 | FROST | FROST |
| 9 | FOCUS | FOCUS |
| 10 | PAN | PAN |
| 11 | PAN FINE | PAN FINE |
| 12 | TILT | TILT |
| 13 | TILT FINE | TILT FINE |
| 14 | PAN/TILT SPEED | PAN/TILT MOVE BLACK |
| 15 | RESET | RESET |
| 16 | LAMP CONTROL | LAMP CONTROL |
| 17 |
| PAN-TILT TIME |
| 18 |
| COLOUR TIME |
| 19 |
| DIMMER-PRISM-FROST TIME |
| 20 |
| GOBO TIME |
