1. Open the front cover, connect the input power cord to the terminal block.
2. Fix the light to the ceiling or wall.
3. Close the front cover.
Dimension:
Model
Dia(mm)
Height(mm)
QY-CL4-R12W
278
99
QY-CL4-R18W
290
102
QY-CL4-R24W
350
109
QY-CL4-R30W
400
121
Package:
Model
Inner Box
Carton
G.W/CTN
QTY/CTN
QY-CL4-R12W
32*32*10.5mm
680*570*360mm
8kgs
10pcs
QY-CL4-R18W
38*38*11mm
810*600*640mm
12kgs
10pcs
QY-CL4-R24W
44*44*12mm
640*490*480mm
7.5kgs
5pcs
QY-CL4-30W
50*50*13.5mm
810*600*640mm
9kgs
5pcs
Parameters:
Model
Light Source
Power
Lumen Output
Ra
QY-CL4-R12W
24pcs 0.5W SMD LED
12W
650-850lm
>75
QY-CL4-R18W
36pcs 0.5W SMD LED
18W
1000-1300lm
>75
QY-CL4-R24W
48pcs 0.5W SMD LED
24W
1400-1600lm
>75
QY-CL4-R30W
60pcs 0.5W SMD LED
30W
1800-2100lm
>75
