Color of aluminum frame: aluminum silver, white painting
Input Voltage: AC 110-240V
Installation: Surface mounted
Certification: CE, RoHS, SAA
Warranty: 3 years
Brand: Qianyi
Size: D262*82mm
Patented products. Counterfeiting is not allowed.
Application: 1. Ceiling 2. Wall
Installation:
1. Open the front cover, connect the input power cord to the terminal block.
2. Fix the light to the ceiling or wall.
3. Close the front cover.
Dimension:
Model
Dia(mm)
Height(mm)
QY-CL3-12W
260
96
QY-CL3-18W
326
98
QY-CL3-24W
395
113
QY-CL3-30W
460
123
Package:
Model
Inner Box
Carton
G.W/CTN
QTY/CTN
QY-CL3-12W
32*32*10.5mm
68*57*36mm
10kgs
10pcs
QY-CL3-18W
38*38*11mm
81*60*64mm
14kgs
10pcs
QY-CL3-24W
44*44*12mm
64*49*48mm
9kgs
5pcs
QY-CL3-30W
50*50*13.5mm
81*60*64mm
12kgs
5pcs
Parameters:
Model
Light Source
Power
Lumen Output
Ra
QY-CL3-12W
24pcs 0.5W SMD LED
12W
650-850lm
>80
QY-CL3-18W
36pcs 0.5W SMD LED
18W
1000-1300lm
>80
QY-CL3-24W
48pcs 0.5W SMD LED
24W
1400-1600lm
>80
QY-CL3-30W
60pcs 0.5W SMD LED
30W
1800-2100lm
>80
Foshan NanHai Qianyi Lighting Co. Ltd is a factory of Export style which was set up in 2014 specializing in desighing and manufacturing all kinds of lighting fixtures. Qianyi Lighting is made up of General factory and a branch factory, taking an area of 10, 000, Stationing over 100 skilled workers, there are 4 production lines inside the factory, including Power-Coating, Aluminum Injection, General Assembling. The annual turn over reaches USD10, 000, 000. The production capacity is increasing by 30% every year so as to meet market demands.
All members in Qianyi Lighting understand we should win the market by good service, quality and better prices. We enforce 7S management to enhance the applying of TUV IS9002 quality management theory. And we have obtained GS-TUV, CE, UL, cUL, ETL, cETL certificates etc. Qianyi Lighting would like to exploit larger market by excellent lightings and service with friends having same ambition in the world.
