| Prod Model: |
PPL-M1241ZB |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Authentication: |
CE/RoHS |
| Output: |
1000PCS Per Month |
| Package: |
Carton/Flight Case |
| Producting Area: |
China |
| LED: |
4 in 1 12PCS 10W CREE LED, RGBW |
| Channel: |
18CH/29CH |
| Dimming: |
Linear Dimming |
| N.W: |
5.5kg |
| G.W: |
6.5kg |
| Packing Size: |
32*25*45.5cm |
| Strobe: |
Electronic Strobe |
| Control Mode: |
Dmx Signal Control |
| IP Rating: |
IP20 |
| Certification: |
RoHS |
| Light Source: |
4-in-1 CREE LED |
| Emitting Color: |
RGBW |
| Control Channel: |
18CH/29CH |
| Voltage: |
AC100-240V, 50~60Hz. |
Product Description
Technicial parameter:
Power Supply: AC100-240V, 50~60Hz.
Power consumption: 145W
LED: 12PCS 10W CREE LED, RGBW 4 in 1
Channel: 18CH/29CH
Strobe: 1-25HZ
Dimming: Linear dimming
X rotate: 540 degree Y rotate: 200 degree
Function: Seven color beam and flower effect. Many amazing Effect
Protect: Electronic automaticlly stable temperature control system.
packing size: 32*25*45.5cm
N.W: 5.5KG
G.W: 6.5KG
| CH MODE | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 | 17 | 18 |
| 18CH | PAN ROTATION | TILT ROTATION | PAN FINE | TILT FINE | PAN/TILE MOVEMENT SPEED | GENERAL DIMMING | GENERAL STROBE | R DIMMING | G DIMMING | B DIMMING | W DIMMING | COLOUR SELECTION | 4PCS OF SECTIONS GOBO SELECTION | BUILT IN PROGRAM | BUILT IN PROGRAM SPEED | EFFECT GOGO POSITION | XY MOTOR |
|
| CH MODE | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 | 17 | 18 |
| 29CH | PAN ROTATION | TILT ROTATION | FINE PAN | TILT FINE | PAN/TILE MOVEMENT SPEED | GENERAL DIMMING | GENERAL STROBE | R1 DIMMING | G1 DIMMING | B1 DIMMING | W1 DIMMING | R2 DIMMING | G2 DIMMING | B2 DIMMING | W2 DIMMING | R3 DIMMING | G3 DIMMING | B3 DIMMING |
| 19 | 20 | 21 | 22 | 23 | 24 | 25 | 26 | 27 | 28 | 29 |
|
|
|
|
|
|
|
| W3 DIMMING | R4 DIMMING | G4 DIMMING | B4 DIMMING | W4 DIMMING | COLOR SELECTION | BUILT-IN PROGRAM | BUILT-IN PROGRAM SPEED | EFFECT GOBO POSITION | X/Y MOTOR REVERSING FUNCTION | RESET AUTO-RUNNING&SOUND -ACTIVATION |
|
|
|
|
|
|
|
