Beam Angle:
120d
Warranty:
3 Years
Emitting Color:
White
Base Material:
Aluminum
Usage:
Tunnel
Life:
30000h
IP Rating:
IP44
Certification:
CE
Power Source:
AC
Electric Current Type:
AC
Input Voltage:
85-265V
LED Chips:
Epistar
Power:
120W
Product Description
Product Description
LED high bay Lighting,LED highbay Lamp,LED indoor light, various LED Industrial Lighting,LED illumination for selection Features:
1) Indoor use 2) High power efficiency > 88% (typical) 3)High luminous efficacy LEDs 4) No UV or IR radiation 5) Cool light can reduce the rise of the ambient temperature 6) Aluminum alloy housing 7) Energy saving and environment friendly
Below is the specification for LED high bay Lighting,If you have specific parameter and requirements for our LED high bay Lighting,Customization is available.
Specification for LED HighBay Light
Product Name
LED HighBay Light
Model No
V-LMD04120
Power consumption
120W
Rate life
30,000 hours
Input voltage
AC 100-240V
LED
Bridgelux or Epistar COB
CCT
6000 ±500K;4000 ±400K;3000 ±300K
Power Factor(PF)
> 0.9
CRI
>70
Luminous Efficacy
85-95lm/W
Beam Angle
45/90/120°
Dimension(mm)
(Φ500*H300mm)
Operating Temp.
-20ºC~ +40 ºC
IP Rate
IP40
Warranty
3 Years
Feature
1) Imported led chip, low light degradation, high luminous efficacy and energy saving. 2) Excellent color rendering, the presentation of the colors more real. 3) Using the lens of rock crystal is satisfied with using in different applications. 4) Special desigh, good heat dissipation structure, 5) World brand's power source, to ensure that the rated life of led light. 6) Green product, environmental protection. 7) Good explosion proof is able to use in flammable and combustible places safely. 8) Anodizing surface, good resistance to corrosion and dustproof.
Options
Model Power Dimension(mm) V-LMD04120 120W (Φ500*H300mm) V-LMD04150 150W (Φ500*H300mm) V-LMD04200 200W (Φ500*H300mm)
FAQ: Q1: What's your delivery time for sample and batch order? A1: Your sample can be ready within one 3-5 working days. For the batch order, the delivery time is around 15 working days.
Q2: What's your payment term? A2: The payment term is 30% by T/T, the balance before shipment. L/C also is available.
Q3: Do you have MOQ(Minimum Order Quantity) for the order? A3: There is no limit for the quantity. Any quantity is available.
Q4:Can we do customized packing? A4: Yes, the printing content can be made according to your requirements.
