| Prod Model: |
LS LED 08E(RGB) |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Laser Power: |
50mw/532nm*2 150mw/650nm*4,400mw/450nm*2 |
| LED: |
177*10mm RGB LED Lamp |
| DMX CH: |
12CH |
| Demonstration Effect: |
Animation |
| Application: |
Indoor |
| Usage: |
Stage |
| Control Mode: |
DMX512 Control |
| Laser Head Numbers: |
8 |
Product Description
Name: LASER LED Light
Model No.: LS LED 08E(RGB)
Laser Power: 50mW/532nm*2 150mW/650nm*4, 400mW/450nm*2
LED Source: 177*10MM RGB LED LAMP
Parameter:
Power Supply: AC 100-120V/AC 220-240V
Laser power 50mW/532nm*2 150mW/650nm*4, 400mW/450nm*2
Rated Power: 150W
Working Mode: Sound Active/ Auto-play/DMX512/Master-Slave
Control Signal: DMX512 signal
DMX Control Channels: 12channels
Operating Temperature: -1° C--35° C
Storage Temperature: -10° C--60° C
Warm-Up Time: < 15 min
Laser Classification: 3b
Modulation: TTL
Size570*570*380cm
CARTON
N. W: 16.00KG
|
CH1 |
LASER |
0 off 1-253 Strobe 254-255 on |
|
CH2 |
SCAN |
1-100 angle choose 101-255 AUTO SCAN |
|
CH3 |
SCAN 1 |
0-100 angle choose 101-255 AUTO SCAN |
|
CH4 |
SCAN 2 |
0-100 angle choose 101-255 AUTO SCAN |
|
CH5 |
SCAN 3 |
0-100 angle choose 101-255 AUTO SCAN |
|
CH6 |
SCAN 4 |
0-100 angle choose 101-255 AUTO SCAN |
|
CH7 |
SCAN 5 |
0-100 angle choose 101-255 AUTO SCAN |
|
CH8 |
SCAN 6 |
0-100 angle choose 101-255 AUTO SCAN |
|
CH9 |
SCAN 7 |
0-100 angle choose 101-255 AUTO SCAN |
|
CH10 |
SCAN 8 |
0-100 angle choose 101-255 AUTO SCAN |
|
CH11 |
Led |
0 off 1-253 Strobe 254-255 on |
|
CH12 |
SAVE |
|
