Solar LED Street Light, SP-1016
UL Certificate
40W To 200W For Selection
105Lm/w High Lamp Efficiency
IP65, 5 Year warranty
1. The 360LED is simply well-designed LED lighting at competitive price with high quality.
2. Key components form: Heat conductive alloy frame, Meanwell HLG driver, Epistar/Singbee LED
3. Different mounting systems for commercials and public lighting: Street Light, Flood Light, Tunnel Light, Canopy Light, Park Light and High Bay Light.
4. Enjoy luminaries with low energy consumption, high light performance and long lifespan.
5. LED is the key to the performance of lightning, it forms the major part of the lamp. Keeping the balance of performance and cost is our first priority.
6. The LED driver is know to be 'heart' of the luminaries. A good driver has to have a good efficiency or it will lower the efficiency of the whole system.
Power(W) |
40W |
60W |
80W |
100W |
120W |
150W |
200W |
|
Modular Number |
2 Bar |
3 Bar |
4 Bar |
5 Bar |
6 Bar |
7 Bar |
7 Bar |
Number of LED |
40 |
60 |
80 |
100 |
120 |
140 |
140 |
Luminous Flux |
4200 lm |
6300 lm |
8400 lm |
10500 lm |
12600 lm |
15750 lm |
21000 lm |
IP |
66 |
66 |
66 |
66 |
66 |
66 |
66 |
Net Weight |
9 Kg |
10 Kg |
11 Kg |
12 Kg |
13 Kg |
14 Kg |
14.5 Kg |
X Dimension |
272 mm |
343 mm |
414 mm |
485 mm |
556 mm |
627 mm |
627 mm |
Rated Voltage |
100-240VAC |
Color Temperature |
6000K / 4500K / 3500K |
Ra |
75 |
