Truck-Mounted LED Displays Truck Full Color P10 LED Display
Price: |
US $ 430-450/Square Meter |
Trade Terms: |
FOB,CFR,CIF |
Min Order: |
5/Square Meter |
Pay Type: |
L/C,T/T,Western Union |
1) Competitive prices
2) CE, RoHS, CCC certificate
3) Outstanding design for LED cabinet.
4) Good after-sales services.
Pixel Pitch | 10mm |
Pixel Configuration | 2R1G1B |
Module Resolution | 16dots*16dots |
Module Size | 160mm*160mm |
Cabinet Size | 960mm*960mm |
Cabinet Resolution | 64dots*48dots |
Module Qty | 36 |
Weight | 40kg/pc |
Display Resolution | 1000dots/Sqm. |
Brightness | 5000cd/Sqm |
Operating Temperature | -20° C ~ +60° C |
Optimal Viewing Distance | 10m |
Gray Scale | 16384 |
Brightness Control | 256 grade |
Protection Grade | IP66 |
Frame Frequency | 60HZ |
Refresh Speed | 300HZ |
Max. power Consumption | 562w/Sqm. |
Average power Consumption | 750 w/Sqm. |
Power Supply | 110V± 15%/50HZ , 220V± 15% /50HZ |
Out-of-control Point | 1/10000 |
Assembly Precision Between PCB | 1 mm |
Power Supply | 110V± 15%/50HZ , 220V± 15% /50HZ |
MTBF | 10000hours |
Life Span(50% brightness) | 100, 000hours |
| Control Mode | synchronization with PC |
| Current Leakage To Grounding | 3mA |
| Operating System | WINDOWS(98/2000/XP/Vista) |
| Color Analysis | In order to make the color matching reach the best white balance effect, the color matching rate of different color brightness is R: G: B /3: 6: 1 |
| Data Transmission | Unshielded twisted- pair net line transmission distance 100m, max transmission distance 130m; Multi-mode Optic fiber transmission distance 500m; Single-mode optic fiber transmission distance 10km. |
| Support Formats | Word files, Picture files, Media and Cartoon files |
| Input Signal Format | VGA, DVI, RGB HV, PbPr (HDTV), Composite, S-Video, TV |
| User Manual' s Language | English |
Prod Model: |
BESD-PH10-011 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Module Resolution: |
16dots*16dots |
Module Size: |
160mm*160mm |
Cabinet Size: |
960mm*960mm |
Cabinet Resolution: |
64dots*48dots |
Module Qty: |
36 |
Weight: |
40kg/PC |
Display Resolution: |
Display Resolution |
Display Type: |
LED Video Display |
Tube Chip Color: |
Full Color |
IP Rating: |
IP65 |
Pixel Configuration: |
1R, 1G, 1B |
Certification: |
RoHS |
Pixel Pitch: |
10mm |
Display Function: |
Video Display |
Application: |
Shopping Guide |
Scanning Mode: |
Static Scan |
Pixel Density: |
10000 dot / m² |
Average Power Consumption: |
350W / m² |
Xinhongxiang Optoelectronics (Shenzhen) Co., Ltd. As one of the most leading LED Products manufacturer in Shenzhen China, covering 10 000 square meters, register capital high up to 30 million CNY, is one high-tech enterprise focus on researching, producing, sale and service of LED products, . Nowadays Xinhongxiang owns fully automatic production lines, independent purifying workshop, researching center, most advanced production and inspection equipments, which guarantee the quality of the LED products. All the products have exported more than 100 countries, such as USA, Mexico, Canada, Brazil, Chile, Argentina, Panama, Colombia, Germany, France, Sweden, Italy, Spain, Russia, Poland, Turkey, Ukraine, South Africa, Egypt, Saudi Arabia, Singapore, Thailand, India etc
Developing History:
From 1996 to 2010, Xinhongxiang Optoelectronics (shenzhen) Co., Ltd, mainly involved in LED encapsulation and LED Display.
Since 2010, owe to enlarge the company scale and build up self-owned brand, Xinhongxiang focus on LED lighting, Shenzhen BESDLED Co., Ltd focus on LED display, business involved in indoor and outdoor LED Encapsulation, LED Display and LED Lighting Products.
LED Display:
Full Color Indoor and outdoor LED Display, single or dual basic color LED signs, LED Curtain, LED Dance Floor, Rental LED Display,
LED Lighting:
LED Bulb, LED Tube, LED Spotlight, LED DownLight, LED Panel Light, LED Street etc,
Comparing with many of LED Manufactures, xinhongxiang owns the following advantages to be your best choice for long term cooperation partner.
1, Fully automatic production lines
Xinhongxiang owns the entire LED manufacturing line, from original Semiconductor to LED chip, then assemble to LED display and LED lighting products.
2, Advanced production equipment
SMD/DIP die bolder, SMD/DIP wire Bolder, Auto Machine of Pouring Glue for SMD/DIP LED, Spectrum and Color Separation Machine, LED oven, Wave solder, Reflow soldering, Spectrum electronic and color tester, temperature and humidity programmable tester, luminance meter etc. Are equipped for our LED Product production.
3, Many Certification approved to clear up the trade barriers
CE, FCC, UL, RoHS, CCC, ISO9001: 2000 etc are obtained.
4, Strong R&D Team
Xinghongxiang absorb many talents, with more than 500 staffs, and including more than 100 engineers and technician, which paves the way for R&D for new products and excellent sales service
5): After-Service,
Principles: Response in time, solve problem ASAP and ensure the use.
Period: During warranty period, free of all maintenance charges;
After Warranty, only charge the material cost.
All the life time, Technology support is free.
