Standard color:
Warm White: 2900-3300K
Commerial White(Daylight white ): 4000-4500K
Cold White: 5700-6500K
Standard Length:
60cm, 90cm, 120cm, 150cm, 180cm, 240cm
Technical Specifications:
1. LED type: 3528 SMD LED
2. Wide voltage Input: AC 100-240 V
3. Frequency: 50-60 Hz
4. PF (power factor ): >0.9
5. Power Efficiency: >87%
6. Harmonic Wave: < 20
7. CRI: Ra>80
8. Use or storage temperature: -20 degree celsius---40 degree celsius
9. Life time: 30000hrs
10. Certificate: TUV, CE, FCC, RoHS & ETL approved.
11. High Lumen + High CRI + Isolated driver
Applications:
1. Restaurant/Hotel/Supermarket
2. Showrooms/ Meeting rooms
3. Factories & Offices
4. Commercial complexes
5. Residential / Institution Buildings
6. Schools, Colleges & Universities
7. Hospitals/Classrooms/Underground Parks
8. Places where need energy saving and high color rendering index lighting
Products Advantages:
1. Energy saving up to 60%, high intensity
2. High quality and good heat dissipation
3. Special different view angles mixing lighting design
4. Instant start, no flickering, no humming
5. High efficiency, constant current driver, with heat protection system can work under unstable voltage
6. Special circuit design, each LED work separately, avoiding the single broken LED influence problem
7. Electric wave resistant
8. No fluorescent flickering
9. No hazard of mercury or lead entering the environment
10. No RF interference, No buzzing noise
11. No danger of broken glass
Our LED Tube Advantage:
1. Each LED brightness is 6.5-8.0 lumen (average 7.5lumen), 10% higher than other factories.
2. Particular circuit design with high efficiency, high quality, lower heat output
3. 15000 hours actual test and proves low light degradation.
4. Patent on structure and heat dissipation design, more durable
5. Padiation report, harmonic report, flicker report, conduction report, IES files.
6. Monthly capacity up to 15000 PCS.
Company Advantages:
1. Professional LED manufacturer both on LED light design and application
2. One of the first company researching and developing LED tube light in China mainland
3. 4 assembly lines, 15 advanced automatic test equipments
4. ISO9001: 2000 UL and ETL management system
5. Prompt delivery and efficent service to customers
6. Professional support on technology and distribute direction
|
Part No. |
Color |
Length |
Led Q' ty |
Lumen |
Net Weight |
Power
(incl. driver) |
|
GL-T8-II-06-T/F |
PW/WW/NW |
60 cm |
144 |
1000-1100lm |
200g |
11W |
|
GL-T8-II-09-T/F |
90 cm |
216 |
1500-1650lm |
270g |
16W |
|
GL-T8-II-12-T/F |
120 cm |
288 |
2000-2200lm |
335g |
21W |
|
GL-T8-II-15-T/F |
150 cm |
360 |
2500-2750lm |
425g |
26W |
|
GL-T8-II-18-T/F |
180 cm |
432 |
3000-3300lm |
545g |
32W |
|
GL-T8-II-24-T/F |
240 cm |
576 |
4000-44000lm |
660g |
42W |
