Model: JCH-TGD-10W
Power: 10W
Working voltage: 12V/24V DC, 100-240V AC
Color: 2800-7000K
Luminous flux: 1000-1100lm
Lifetime: >50000hours
Ra: >80
Power Factor: >95%
Efficiency: >90%
Beam degree: 120° -140°
Body Size: 190mm
With holder: 1500 mm
Lamp material: Aluminum die-casting and toughened glass
Housing color: Green/ Yellow/ Red/ Silver gray
Battery: Li-ion, 7.4V/ 4800mA
Workign temperture: -40~60 Centigrade
Warranty: 3years
Certification: CE&RoHS
NW: 3.2KG
Features:
1)High efficiency, high brightness, energy saving.
2)CE & RoHS approved, Quality Guaranteed
3)Environmental protection, no pollution(no lead and mercury), no radiation, conducive to the recycle and reuse;
4)Color having the diversity, controllability;
5)Widely used in building facades, the Plaza lights, garden trees and the landscape greening lighting and
The outdoor places where need spot lighting and lights decoration
6)Reliable quality & credit, 2 years warranty and 50.000 hours lifespan.
7)Chargeable battery: Working hours last for 4 hours with full charged battery.
Trade terms:
1. Payment: 30% deposit before production, 70% balance to be paid before delivery.
2. Production lead time for 100~500PCS: About 7days, 500~1000PCS: About 15days.
3. Sample can be delivered in 3days.
4. Shipping freight are quoted under your requests.
5. Shipping port Shenzhen or HongKong, China.
6. Discounts are offered based on order quantities.
Application:
Emergency lighting, vehicle maintenance
Light Source | High power Integrated LED |
LED Chip | Epistar /Bridgelux |
LED Total Power | 10W |
LED Luminous Efficiency | 90LM/W |
LED Initial Flux | 900-1000lm(Tj=25°C) |
Average Illumination and Effective Illuminated Area | 1M Height | ≥480LUX |
2M Height | ≥150LUX |
3M Height | ≥40LUX |
4M Height | ≥35LUX |
Color Index(CRI) | Ra > 72 |
Color Temperature(CCT) | Warm white: 2700-3500K Nature white:3500-5000K Cool white: 5500-6000K |
Beam Angle | The Horizintal Axis:120° ; The Vertical Axis:60°; |
Light Distribution Curve(Beam Pattern) | Asymmertric(Bat Wing)/Rectangular Beam |
Battery type | Battery capacity can be customized |
Running time |
Running can be customized |
Housing color | Color can be customized |
PCB protection | Running with constant current,over-charging and dis-charging protection |
LED indicator | Charging indicator | Indicator LED flash red and green |
Full charge | Indicator LED turn to green |
working | Indicator LED off |
Battery capacity drop to 10% Battery capacity drop to 5% | Battery Indicator LED flash red one time/second
Indicator LED flashes red two times/second |
Input Voltage | 12V/24V |
Frequency | 50/60Hz |
Total Harmonic Distortion(THD) | <20% |
Storage Temperature | -40°C--60°C |
Working Temperature | -4 0 °C --60°C; |
Charging Temperature | 0 °C --45°C |
Light Body and Lampshade Material | Aluminum and PC |
Warranty | 2 years or 500 times charging cycle |
IP level | IP65 |
Battery capacity | LI 3600mAH |
Packing | 1ps/box, 8pcs/ctn |
Unit Size | L175*W160*H180mm |
White Box Size:(mm) | L175*W160*H180mm |
Carton Size:(mm) | L346* W322*H362mm |
Working time: | 5 hours |
