Specification of the SL-BL003-100 DC24V LED light bar.
1, Power: 10W DC24V LED light bar
2, Voltage: DC24V DC24V LED light bar
3, Size: 360*23*16mm DC24V LED light bar
4, Luminous Flux: 700-800Lm DC24V LED light bar
5, Color Tempreture: 3000-7000K( warm white, normal white and cool white) DC24V LED light bar
6, Beam angle: 9*50° /15*60° DC24V LED light bar
7, LED chip: CREE( made in USA) DC24V LED light bar
Except the size of 360*23*16mm DC24V LED light bar, we even have the DC24V LED light bar sizes of:
1, 200*23*16mm DC24V LED light bar
2, 300*23*16mm DC24V LED light bar
3, 360*23*16mm DC24V LED light bar
4, 470*23*16mm DC24V LED light bar
Except the warm white, normal white and cool withe DC24V LED light bar, we even have the DC24V LED light bar colors of;
1, RED DC24V LED light bar
2. GREEN DC24V LED light bar
3, BLUE DC24V LED light bar
4, RGB DC24V LED light bar
About the DC24V LED light bar
1, The DC24V LED light bar should use in the light box which it's depth is big than 7cm for one side light box 12cm for two sides light box, if the light box is small than7cm, we will recommend you using the LED back light.
2, The DC24V LED light bar is use in the sides of the light box. If the width of the light box is small than 1.2m, you just should install the DC24V LED light bar in two side of the light box. If the width is more than 1.2 and the length is more than 1.2m, you should install the DC24V LED light bar in all sides of the DC24V LED light bar.
3, The biggest size of the light box for DC24V LED light bar is 3m*3m, if the light is big than 3m*3m, it will has dark area in the middle of the light box.
4, The DC24V LED light bar has the beam angles of 10*45° And 20*60 for epistar DC24V LED light bar, and 9*50 and 15*60° . You should choose the best beam angle for you light box. Nomally, if the width is not very big, you should choose the samll beam angle, if the width is big, you had better choose the big beam angle.
Why you choose us.
1, Our company started in the year of 2002, we are the biggest manufacturer of LED display light in China.
2, We focus on the LED display light and LED advertisement light, we will offer you the whole solution to you.
3, We can offer you the best quality and service to you. 3 time quality control for each product, 100% testing to make sure each product has a good quality when it is finish.
4, Short delivery time, sample would send to you in 3 days, 100pcs-500pcs will send you in 8 days. 1000-3000pcs will send to you in 3 weeks.
5, If you have your own requirement on the product, please tell us, we will let our engineer design according your requirement, we can offer you the solution from design to manufaturer.
6, If the product has any problem(not caused by artificial reason), we will fix for you, if we can't fix it, we will resend a new one to you.
About the service of the DC24V LED light bar.
1, If you have any question on the DC24V LED light bar, I will reply you in 2 hours.
2, If you have any requirement on the DC24V LED light bar, please kindly tell us in advance, so that
We can talk with our engineer and then offer you the best solution.
FUJIAN SUNLIGHTE OPTOELECTRONICS TECHNOLOGY Co., Ltd. Established in 2004 with major business of Display lighting manufacturing, such as LED Module, LED Backlight, Pop up light and roll up light. To catch the trends of the latest lighting technology and offer higher energy-efficient products, we started R&D work of LED lighting products in May 2008, and mass producing from October 2009;
SLT's products;
LED Module, LED Light Bar, LED Backlight, LED Light Panel, LED Display light, LED Spot Light, LED Trade Show Light
SLT's R&D Ability;
A, with a senior R&D team of 11 members in total, 6 of which have 6 years experience in LED Lighting research work.
B, with well furnished laboratory, like LED spectrophotometer, Goniophotometer, Lumen Tester, LED Spectrophotometer instrument, Luminous Intensity-angle Intensity measurement System, High-power LED Spectrophotometer, LED Lifetime tester and so on.
C, We possess around 30 technical achievements, 23 of them have been patented.
SLT's Production Capability;
A, with professional workshop (4300SM), 10 PCS SMT machine
B, Monthly production is up to tens of thousand PCS
SLT's service policy;
Offering 3 years warrantee of after-sales service
SLT's Qualifications;
ETL, PSE, CE, FCC and compliance with RoHS standard.
SLT's high efficiency sales team;
A, with a sales team of 12 members in total,
B, 4 of which have 5 years experience in international trade, two of which have 10 years experience regarded, many of them
Do familiar with international practice.
Xiamen Sunlighte Industry & Trade Co., Ltd. Locates in a beautiful seaside garden city of Xiamen, Fujian province, which is one of the most important international traffic hubs in China, it's only three hours express train from HongKong, serves 167 domestic & international routes operated by 42 airlines and world's top 20 shipping companies.
So we do not only offer high quality products, delivering products on time, and offering high efficiency of international trade operation also. The total cost at your side regarded will be cut down, and make you will benefit well from our high efficiency service.
Thanks a lot for being interested in our products, you are warm welcome to contact us in time for further inquiries on SLT company or on our products' details, we look forward to establish long-term cooperation relationship with you.
