Electrical characteristics
1. Solar panel: 0.55W, 17% efficiency
2. Li-ion battery: 3.7V 800mAh
3. Switch Pin: Turn on/off the light by hand
4. LED: 16PCS, SMD 3528, 1W, 100Lumens
5. Light mode: Dark/Dim/Bright
Dim: Weak lighting for saving power when no motion
Bright: Motion activate for lighting when people walk near
6. Protect function: Over charging, over discharging, over current, short circuit
7. Advantage for electronic:
A) Constant voltage 4.2V charging type
B) Input current limited
C) Output current limited
D) Backflow current proof for solar cell
E) High efficiency
F) Famous brand component: South Sunlight
8. Stainless Material: ABS+aluminum(sand blasting)
Operation Instructions
1. Unlock and activate the device
The internal battery is locked from factory for safety shipment, so users have to use supplied Key pin to click the "on/off" socket and unlock the battery and lighting system.
2. How to install the device?
Please use the supplied Expansion pillar-hinge and screws to mount the device on Pole or wall anywhere outside you want for lighting.
3. Charging via solar panel:
Please install the unit face south and make sure the solar panel can get the good sunlight directly without any shelter or glass.
4. Night sensor function
It will auto turn on Dim light when in darkness or at night, and auto turn off when in daytime or bright area.
5. Dim light mode
In order to save power, it will auto turn on Dim light when no Motion over there, but the brightness also can work as signal light.
6. Bright light mode
When people walk around 2 meters close, it will turn on bright light.
