Technical parameters:
*Power: 100-240V, 47----63Hz
*Comsued power: 300W
*Ballast: Electronic ballasts and AC/Dc power supply
*Lamp: Philips Lamp (life: 2200 hours Color temperature: 8000K)
*Color wheel: 14 color + blank color wheel
*Gobo: 17 fixed gobo + blank gobo
*Prism: Rotation 8-face prism, Bilateral rotation. Beam effect could stretch and close
*Lens: High precision optical lens
*Soft effect: Adjustable soft spot
*Focus: Linear adjustment0— 100%
*Pan/Tilt: X axis 540° Y axis 250° Automatically accurate positioning
*Beam angle: Parallel beam angel 0 3.8°
*Strobe: Double lens strobe (0.5-9 times/ second)
*Motor; 11pcs mute sound motor, 2pcs three phase motor, 16bit driver
*Transmission mode: DMX512 receiver
*Channel mode: 16 DMX512 Channel
*Structure: Heat-proof plastic + module pressing alloy materials
*Cooling system: Convection, Fan cooling
*Panel Display: LCD liquid crystal display.
*Appearance: High temperature molded plastic + alloy
*IP level: IP20
*Single carton Size 1pcs (L x W x H): 450x420x510(mm)
*N. W; 18.5KG
*G. W; 22KG
*2 pcs to a flycase (L x W x H): 755x660x680(mm)
*N. W: 37KG
*G. W: 60KG
Guangzhou Mintforbers Lighting Equipment Co., Ltd. is a high-tech enterprise specializing in R&D, design and sales of stage lighting, architectural lighting and and other professional stage lighting products. Our company was established in the year 2007 and we have our owner sales office in Shenzhen City. The light production base located in the Baiyun district, we own professional production troop engaging in R&D, production and sales.
Our major products include LED light, Moving head light, Scanner, Laser light, Professional audio and so on. Also we supply OEM service for customers from all parts of the world.
