Technical parameter
Voltage: 100V-240V/50-60Hz, Ballast: Electronical ballast music
Power: 350W
Lamp: OSRAMSIRIUS HRI 330W(optional YODEN R17 350W)
Color Temperature: 7500K
Average life: 1500H
Number of channels: 23channels
Protection: IP20
Size: 409X419X541mm
Weight: 23KG
Features:
Control: 23 international standard DMX512 control, master-slave mode, self-propelled mode.
LED display, DMX 3-pin or 5-pin input
Lens: YiGansu anti-reflective coating glass lens
Color: 6colors+with a blank, with full color or half color capabilities, also has a UV insulation film, CMY color or mixing system
Fixed pattern: With 14 fixed gobos +blank
Rotating pattern: With 8 rotating gobos plus blank gobo can freely swap replacement
Strobe: 0-13 times/sec. With random strobe
Prism and the prism rotation: Rotating 3 facet prism, can be bi-directional rotation, prism rotation, with 16 macrofndions prism effect
Soft Effect: You can adjust the angle soft spot
Aperature: 5% to 100%, with aperture effect
Focusing: Liner electron adjustable
Light projection range: X to 540degrees, Y to 270degrees, can automatically correct positioning.
Beam angle: 5.4 to 28 degree
Strobe: Two-piece Strobe(0.5-9times/sec. )
Motor Quantity: Total 16 ultra-quiet motors, two-phase motor, 16bit drivers
Other features: Remote control lamp switch function, display lamps, lamp usage time
Appearance: High temperature molded plastic +alloy
Guangzhou Baiyun District Shijing Town Meilaite Stage Light Equipment Factory was established in 2001 in Guangzhou.After a year's development from outdoor lights to indoor casino main lights, our company has formed one stop casino and outdoor light service.
Today, we still keep the leading status in outdoor series industry.We are the first factory which makes DMX512 moving head searching lights and high-power DMX512 moving head color-change lights.With the same technology, we have made high-power DMX512 moving-head and scanner series.This success is based on our tactic plan and professional orientation.
We have several senior engineers and more than 100 experienced technical workers.All our workers comply with ISO9001:2000 quality certification system standard.Our product quality has reached international quality standard.Also we are successful in projects and international Business.Till now, we have finished more than 200 projects and we have the trading network in more than thirty cities in China.
