Feature:
1.fast moving head,and quick response,accurate positioning.
2.powerful beam effect and beautiful spot effect.
3. bring more fun and colorful patterns. "Net" pattern prism in aperture reaches the maximum brightness, with minimal loss to filling stage
4.With 2 prism effect, the effect of rotating prism is very useful,A prism broader the angle of the light.
Technical Parameter :
Power Input: 100-240V,50/60Hz
Magnetic ballast and AC/Dc power supply
Power Dissipation:420W
lamp: 280W (Color temperature: 8000K)
Channel mode: 16 / 24 DMX512 Channel
Pan scan:540°(16bit) Electric correction
Tilt scan:270° (16bit) Electric correction
Amazing dot matix, four tact switch, 180° turning show
Color wheel: one color wheel, 13 kinds of color chips in one color wheel
Static Gobo: 10 gobos
Rotation Gobo:9 gobos
Effect Wheel: one Rotation eight prism,one Rotation six prism effect move , frost
0-100% mechanical dimming, mechanical dimming and free dimming available.
strobe macro control available.
Lens optical system achanical focus .
beam angle3.8°-45°
Over heat protection
IP level :IP20
Packing Size: 523x337x570mm
Net weight:20 KG
channel chart:
| channel | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 |
| function | X | X fine | Y | Y Fine | X/Y speed | power/macro | gobo | Gobo wheel fine | speed | Static gobo | Rotation gobo |
| 12 | 13 | 14 | 15 | 16 | 17 | 18 | 19 | 20 | 21 | 22 |
| Gobo rotation | Gobo wheel fine | prism | Prism rotation | frost | zoom | Zoom fine | focus | Focus fine | empty | shutter |
| 23 | 24 |
|
|
|
|
|
|
|
|
|
| dimmer | Dimmer fine |
|
|
|
|
|
|
|
|
|
Trade terms:
| Price Term | exw price |
| Payment terms | T/T,Paypal,Western union |
| Shipping Way | 1.By express(DHL,Fedex,Ups,EMS) |
| 2.By air |
| 3.By sea |
| Sample time | 1-3 workdays |
| Production time | general 5-10 days,depend on your order quantity |
| Packing | 1.Standard Carton |
| 2.Flight case |
| Warranty | 1 years |
| After-Sell server | 1.If there is some problems with the product,please describe it and sent thenecessary picture or video to us for analyzing. |
| 2.Then we will guide you how to fix it and provide free accessories if needed. |
| 3.1year quality guarantee at least, and we will provide free parts for replacement if any problem belong to us during the period(Delivery cost paid by customer);1 year later, we can provide spare parts for replacement based on certain charge. |
