RGB 18W 300X300mm LED Light Panel
Specifications
Input voltage: DC36-42V
Power consumption: 20W
Luminous flux: 1300-1400LM(cool white)
Color temperature: 2800-6500K
Life time: >25000h
Operating temperature: -20 degree celsius to 40 degree celsius
Humidity operating: 10-80%
Certifications: CE RoHS
Features:
1. Use Samgsun or Seoul semiconductor LED
2. Very thin thickness only 13.5mm
3. Use Mitsubishi acrylic plate
4. Use China famous LED driver or Taiwan Mean Well driver
5. With very good smoothly light and very nice back plate
6. Have very competitive price
Applications
1. Hotels
2. Conference/Meeting rooms
3. Factories &Offices
4. Commercial purposes
5. Residential/ Institution buildings
6. Schools, colleges and universities
7. Hospitals
8. Places where energy saving and high color rendering index lighting are needed
Installation
Packing
|
Model |
Power |
Input voltage |
Luminous flux |
CCT |
CRI |
Beam angle |
Dimmable |
Life |
|
MPL303020A |
20W |
100-240V |
1300LM |
2800-3000K |
70 |
120° |
YES |
25000H |
|
MPL303020A |
20W |
100-240V |
1350LM |
4000-4500K |
70 |
120° |
YES |
25000H |
|
MPL303020A |
20W |
100-240V |
1400LM |
6000-6500K |
70 |
120° |
YES |
25000H |
|
(Name) |
300*300mm LED panel light |
600*600mmLED panel light |
1200*300mmLED panel light |
1200*600mm led panel light |
|
(Watt) |
20W |
36W |
36W |
70W |
|
(Model) |
MPL303020A |
MPL606036A |
MPL3012036A |
MPL6012054A |
|
(CCT) |
2700K/4000K/6000K |
2700K/4000K/6000K |
2700K/4000K/6000K |
2700K/4000K/6000K |
|
(Lumen) |
1300-1400lm |
2425-2610lm |
2400-2600lm |
4600-5000lm |
|
(CRI) |
>80 |
>80 |
>80 |
>80 |
(Input Voltage) |
AC100-240V |
AC100-240V |
AC100-240V |
AC100-240V |
|
(Lifetime) |
40000h |
40000h |
40000h |
40000h |
|
(Beam angle) |
120° |
120° |
120° |
120° |
|
|
- |
- |
- |
- |
