1Construction Description |
Each pixel contain 1 red 1 pure green 1 pure blue total 3 pcs LED
Pitch 6mm, resolution 27777 dots/ |
2Professional analysis |
|
No. |
Professional analysis content |
Analysis item |
|
1 |
Color matching analysis |
In order to make the color matching reach the best white balance effect, the color matching rate of different color brightness is RGB/361 |
3Pixel Parameter |
No. |
Item |
Parameter |
1 |
Pixel pitch |
PH6mm |
|
2 |
Pixel configuration |
1R 1PG 1PB |
4Tube Chip Parameter |
No. |
Item |
Wavelength |
Brightness |
Model No. |
|
1 |
Red tube chip |
620-625nm |
180-220mcd |
porstar-A1 |
|
2 |
Pure green tube chip |
520-525nm |
360-400mcd |
porstar-A1 |
|
3 |
Pure blue tube chip |
465-470nm |
80-120mcd |
porstar -A1 |
5Screen Body Technical Parameter |
|
1 |
Screen body area |
6m(L)× 3.28m(H) = 19.8 m 2 |
|
2 |
Whole screen pixels |
Real pixels: 800dots(L)× 432dots (H)=345600dots |
4× 7=28 cabinets |
|
3 |
Unit box |
|
Size: 976mm× 732mm |
|
4 |
Display brightness |
1, 500 CD/M 2 |
|
5 |
Brightness adjustment |
256 grade automatic, 8 grade manual, |
|
6 |
Drive Mode |
1/8scan |
|
7 |
View Angle |
120 degreesleft and right view angle |
|
8 |
View Distance |
3-60 meters |
|
9 |
Grey Scale |
256 grades, |
|
10 |
Display Colors |
≥ 16M |
|
11 |
Frame rate |
60 Frame |
|
12 |
Refresh rate |
360HZGuarantee that the picture will not tingle when the pick up camera is kinescoping |
|
13 |
Control Mode |
To be synchronized with computer monitor |
|
14 |
Data Transmission |
Parallel RS422 mode |
|
15 |
Screen Lifespan |
> 100, 000 hours |
|
16 |
Blind Spot Rate |
≤ 0.0002 |
|
17 |
Operating Voltage |
AC100V± 240V 5060HZ |
|
18 |
Screen Body Power Consumption |
Max: 800w/M 2, Average: 400w/M 2 |
|
19 |
Color Temperature |
6, 500K± 500 |
|
20 |
Screen body weight |
Less than 60KG/ M 2 do not include outer frame |
|
21 |
Control Distance |
100 meterswithout relayoptical fiber transmission 500M-10, 000M |
|
22 |
System Working Environment Temperature |
-10+50 |
|
23 |
System Working environment humidity |
10%95%RH |
|
24 |
System Operating Platform |
WINDOWSWIN98WIN2000 WIN XPfriendly interface, Keep the interface for the secondary development |
