LED Light Source: CREE
Input Voltage(V): 100~277V
Lamp Power(W): 20w-200w
Lamp Luminous Flux(lm): 1800-18000
Lamp Luminous Efficiency(lm/w): 90lm
CRI (Ra>): 70
Color Temperature(CCT): Cool White
Working Temperature: -40 - +50
Working Lifetime(Hour): 100000
Lamp Body Material: Aluminum Alloy
IP Rating: IP68
Certification: CE, Energy Star, EMC, ETL, ROHS, UL
Warranty(Year): 5years
Place of Origin: China (Mainland)
Model No:
|
YY-L40
|
YY-L50
|
YY-L60
|
YY-L80
|
YY-L90
|
YY-L120
|
YY-L150
|
YY-L200
|
Total power:
|
40W
|
50W
|
60W
|
80W
|
90W
|
120W
|
150W
|
200W
|
Nominal Lumens
|
3,720
|
4,250
|
5,580
|
7,200
|
7,650
|
11,160
|
13,500
|
16,650
|
Drive Current
|
350 mA
|
450 mA
|
300 mA
|
350 mA
|
450 mA
|
300 mA
|
350 mA
|
350 mA
|
# oF LEDS
|
36
|
36
|
60
|
60
|
60
|
120
|
120
|
144
|
System efficacy
|
93LM/W
|
85LM/W
|
93LM/W
|
90LM/W
|
85LM/W
|
93LM/W
|
90LM/W
|
90LM/W
|
Dimensions
|
LENGTH : 400mm
WIDTH : 250mm
HEIGHT : 65mm
WEIGHT: 5.5 KG
|
LENGTH : 650mm
WIDTH : 260mm
HEIGHT : 82.8mm
WEIGHT: 9.5 KG
|
LENGTH : 795mm
WIDTH : 372mm
HEIGHT : 82.8mm
WEIGHT: 13 KG
|
Description
|
Replacing 80-120w HPS
|
Replacing 100-150w HPS
|
Replacing 150-200w HPS
|
Replacing 230-280w HPS
|
Replacing 250-300w HPS
|
Replacing 300-400w HPS
|
Replacing 400-500w HPS
|
Replacing 600-800w HPS
|
Appearance description
|
Material: Die Cast Aluminum
Light Color option: Cool White
Warm White
Custom color
LENS: Super Clear Tempered Glass
|
LED light engine description
|
High quality Bridgelux 700Ma 45Mil
Efficacy : up to 150lm @ 350Ma (per watt)
Rated Life of 100,000+ hrs
Operation temp: -30 oC to +40 oC
No toxic chemicals/Rohs compliant
70%-80% saving compare to HPS/MH
|
Electrical characteristics
|
Wide AC input: 90-305 VAC
(UL marking: 100-240VAC/277VAC)
Power Factor: ~0.98
Total Harmonic Distortion: < 10%
Surge protection: IEC/EN 61000-4-5
EMC test standard
|
Product installation
|
Easy installation – plug and play
Pole mount dimension : 58 -63mm
|
Product qualification
|
5 years warranty
Highest Ingress Protection rating : IP68 CE: Recognition with CNAS
ISO 14001: Recognition with IAF & CNAS
ISO 9001: Recognition with IAF & CNAS
UL certify: ANSI/UL
|
Professional Manufacturer of LED Lighting (We have passed the SGS authentication, if need the report, Pls contact Robin. )
Located in the beautiful city, Xiamen. Xiamen Royoled Photoelectric Technology Co., Ltd. Specializes in R&D, production, marketing of LED lighting products. We are not only a developer and manufacturer specializing in top-quality LED Downlights, LED T8/T5 Tube lights, LED Spotlights, LED Bulbs, LED Panel lights, LED interior lighting, LED exterior lighting, etc., but also an excellent solution provider for high-power LED lighting application. Our products are sold to different market throughout the world, widely used in projects for interior&exterior lighting, city illumination, stage illumination and industrial & commercial lighting, etc.
Xiamen Royoled Photoelectric Technology Co., Ltd. is well equipped with the most advanced automatic production machine and testing equipment. We abides strictly ISO9001: 2000 and SGS in operation. Our LED lighting products have passed CE\RoHS\EMC\UL certificates, which is the best proof of our internationally-leveled products. Taking market as the guide, we pay high attention to requests from different clients. With our constant efforts, we have established very good reputation.
WHY CHOOSE US?
Professional. We provide custom-design service, improve product according to customers' requirement. We take every order seriously, be it big or small.
Flexible and make the production more efficient. We control the quality 100% strictly. All our effort are to bring 100% satisfaction to our customer.
Xiamen Royoled Photoelectric Technology Co., Ltd. Working with high enthusiasm and effort to win all our customers' trust and support. "Top-quality, Customer First", Xiamen Royoled Photoelectric Technology Co., Ltd. is making our best to provide most competitive and top-quality LED lighting products.
ROYOLED, Light the world, Shine the global, Brighten happy life!
Primary Competitive Advantages:
OEM Capability\Production Capacity
Reliability\Reputation
Buyer's Specifications Accepted
Comprehensive Services
Product Range:
High-power LED lights\LED downlights\LED tubes Light\LED bulbs Light\LED spotlights\LED Ceiling Light \LED Panel light...
