Front Advertising Indoor LED Screens P6 for 27777 Dots / M2
Applications:
For Events, Wedding Ceremony, TV Stations, Contest - TV Station, Contest, - School, TV Shows, Exhibitions, Indoor and outdoor architectures, Commercial Marketing Performances, Public Square etc. They can replace any posters and static billboards and display any animation, video, or text with sound, and supply different experience and effect for clients' advertisements.
Descrition:
01). P6, P5, P4, P3 Available
02). Easy to install and maintenance
03). Widely used in indoor and outdoor advertising and media promotion, such as Exhibition, Shopping mall, Football Stadium, Party etc.
04). High quality with Vivid visual effect
05). Colorful moving videos and pictures
06). Environmental-protected and saving cost
07). Good sales service
08). Prompt delivery
|
Pixel pitch |
P6 |
|
Module size |
96*192mm |
|
pixels Density |
27777 dots/SQM |
|
Pixel configuration |
1R1G1B |
|
LED specification |
SMD3528 3-in-1 |
|
Pixel resolution |
16x32 |
|
Working voltage |
DC5V |
|
Cabinet size |
960*960*150mm |
|
Quantity of Module |
50pcs |
|
Power supply |
5V/40A* 4 pcs |
|
thermal discharge |
fan*4 pcs |
|
Pixel per cabinet |
256x192dot |
|
Best viewing distance |
5-- 50m |
|
Best viewing angle |
120°(H) /90°(V) |
|
Temperature |
storage: - 35ºC~+ 85ºC |
|
working: '- 20ºC~+ 65ºC |
|
Operation humidity |
≤90 ~ 95% |
|
Thickness |
15cm |
|
Working voltage |
AC220V ± 10% |
|
Average consumption |
450-650 w/SQM |
|
Max. consumption |
≤1200 w/SQM |
|
Current |
≤20mA(single LED) |
|
PC |
Pentium 4 or above |
|
Operating system |
Win XP/ Vista/window 7 |
|
control method |
Synchronization |
|
Driving device |
Constant Current |
|
Drive type |
1/16 Scan |
|
Refresh frequency |
≥120Hz/s |
|
Grey scale/colors |
256 levels of each color(R/G/B)/ 16.7M colors |
|
Brightness |
≥2500cd/SQM |
|
Brightness adjustment |
255 levels of each color(R/G/B) by software |
|
Video Signal |
PAL/NTSC |
|
Control system |
DVI display card + full color controller card |
|
MTBF |
≥10, 000 hours |
|
Life span |
≥70, 000 hours |
|
Flatness |
Tolerance of pixel pitch≤0.3mm |
|
Tolerance of modules between ≤1.5mm |
|
Communication distance |
no less than 100 meters (network cable) |
