Type: pH8
Pixel pitch(mm): 8
Pixel density(DOT/m² ): 15625
Pixel specification: 1R1G1B
View degree: 110
Module size: 256mm*128mm
Module resolution(DOT * DOT): 32*16
Module number / cabinet: Depend on cabinet size
Grey level(level): 4096
Refresh rate(Hz)>380
Brightness(CD/)≥ 8500
Weight(kg/m² ): 35
Display color(color): 16777216
Visual distance(m): >8Power(w/)Max: 800
Average value: 266/m²
Drive mode1/4 scanning, Constant-current drive
Blind spot rate: ≤ 0.0003
Lifetime: 50000 hours
Working voltage (V): 220∨ /110V± 15%
Working temperature: (º C)-20º C~60º C
Working humidity: (RH)10%~90%RH
Control mode Synchronous control
Control systemPCTV card +DVI display card+ main control card +fiber transfer
SoftwareLED by studio or the user
Computer WINXP/WIN2000/WIN98 etc.
Display cardDVI
Control distance Twisted-pair 100m, Fiber ≥ 500m
|
No. |
Name |
Chip brand |
Chip type |
Wavelength |
Brightness |
Number |
|
1 |
Red |
Epistar |
9mail |
620-624nm
|
500-600mcd
|
1pc |
|
2 |
Green |
Epistar |
12*13 mail |
522±4nm
|
1100-1320mcd
|
1pc |
|
3 |
Blue |
Epistar |
12*13 mail |
470±3nm
|
260-300mcd
|
1pc |
