LED especificación:
NO.ColorChip brandWavelengthView AnglePlace of origin
1RedSilan625nm140°/140°China
2GreenSilan520nm140°/140°China
3BlueSilan467nm140°/140°China
Cabinet specification:
NO.ItemParameter
1ModelHTS-ORM-8
2 Pixel pitch8mm
3Pixel configuration1R1G1B
4LED typeSMD3535
5Module size256*256mm
6Module resolution32*32
7Cabinet resolution64*64
8Cabinet size512*512mm
9depth75mm
10Density15625 dots/
11Brightness≥4800 NIT
12Best view distance≥8m
13Max. power consumption 300W
14Ave. power consumption 120W
15Cabinet materialDie-casting aluminum
16Weight/tile8 KG
17Weight/sq.m30 KG
18Colors281 trillion
19Refresh rate≥1440Hz
20View angle140 degree for vertical and horizontal
21Out of control pixel rate<1/10000
22MTBF>5000 hours
23Lifespan100000 hours
24Signal input sourceComposite, S-video, Component, VGA, DVI, HDMI, SDI, HD-SDI
25Working voltageAC 100/200v 50-60Hz
26Control distanceEthernet cable: 100m, Multi-mode optical fiber: 500m, Singel-mode optical fiber: 20km
27Operation environmentTemperature: -30 to +60, Humidity: 10%-95%
28Protection levelIP65
|
LED especificación: |
|
NO. |
Color |
Chip brand |
Wavelength |
View Angle |
Place of origin |
|
1 |
Red |
Silan |
625nm |
140°/140° |
China |
|
2 |
Green |
Silan |
520nm |
140°/140° |
China |
|
3 |
Blue |
Silan |
467nm |
140°/140° |
China |
|
Cabinet specification: |
|
NO. |
Item |
Parameter |
|
1 |
Model |
HTS-ORM-8 |
|
2 |
Pixel pitch |
8mm |
|
3 |
Pixel configuration |
1R1G1B |
|
4 |
LED type |
SMD3535 |
|
5 |
Module size |
256*256mm |
|
6 |
Module resolution |
32*32 |
|
7 |
Cabinet resolution |
64*64 |
|
8 |
Cabinet size |
512*512mm |
|
9 |
depth |
75mm |
|
10 |
Density |
15625 dots per square meter |
|
11 |
Brightness |
≥4800 NIT |
|
12 |
Best view distance |
≥8m |
|
13 |
Max. power consumption |
300W |
|
14 |
Ave. power consumption |
120W |
|
15 |
Cabinet material |
Die-casting aluminum |
|
16 |
Weight/tile |
8 KG |
|
17 |
Weight/sq.m |
30 KG |
|
18 |
Colors |
281 trillion |
|
19 |
Refresh rate |
≥1440Hz |
|
20 |
View angle |
140 degree for vertical and horizontal |
|
21 |
Out of control pixel rate |
<1/10000 |
|
22 |
MTBF |
>5000 hours |
|
23 |
Lifespan |
100000 hours |
|
24 |
Signal input source |
Composite, S-video, Component, VGA, DVI, HDMI, SDI, HD-SDI |
|
25 |
Working voltage |
AC 100/200v 50-60Hz |
|
26 |
Control distance |
Ethernet cable: 100m, Multi-mode optical fiber: 500m, Singel-mode optical fiber: 20km |
|
27 |
Operation environment |
Temperature: -30 to +60, Humidity: 10%-95% |
|
28 |
Protection level |
IP65 |
Shenzhen HTS Optoelectronic Technology Co., Ltd is a Shenzhen-located high-Tech enterprise which specializes in the R&D, manufacturing, salesand serviceof LED display and LED lighting products. Thanksto the human-base management policy, advanced production machines and test equipments as well as rich options of raw material resource, HTS has developed a professionalplatform to become a modern enterprise. According to the demand of the market HTS has developed a Full product range through industry-chained opetatio model and HTS aims to rank. In the front line of the LEDdisplay industry. Of professional designers and software and hardware systems personnel, creative and unique copy talent.
HTS is located in Dalang, Longhua, Baoan District, which enjoys a group of influential experts in LED industry, a professional R&D team and highly-skilled manufacturing staff. It occupies more than 6000 square-meter free-dust and static-proof production area which covers several automated assembling lines, many advanced production machines and optimized testing equipments. Aim to the high level market, HTS insists developing MID and high-end products, serves the customers as the center of our work, strives for survival on the basis of quality, employs the managing idea of searching development by integrity, we manage to win the customers and the market by our sincerest heart, most advanced technology, best-quality products and most satisfactory service.
