LED Chip
No. LED constitution Types
1 SMD2121 Epistar
Module Specifications
1 Pixel Pitch 3.91mm
2 Module Resolution 64dots ×64dots
3 Module Pixles 4096 dots
4 Module Size 250mm × 250mm
Cabinet Specification
1 Cabinet Size(WXH) 500mm × 500mm
2 Cabinet Resolution 128dots × 128dots
3 Module Quanity 2*2=4pcs
4 Pixel Density per Module 16384dots/m2
5 Pixel Density 65536dots/m2
6 Material die-cast aluminum
7 Cabinet Weight 7.5KG
Screen Parameters
3 Brightness 1600cd/
4 Driving Method 1/10scan
5 View Angle Horizontal 140° Vertical 140°
6 Min. Viewing Distance ≥3 meter
7 Gray scale 8192×8192×8192
8 Colors 549 Billion
9 Refresh rate ≥1500Hz
10 Input Voltage AC220V/60Hz or AC110V/60Hz
Power Consumption (Max.
11 800/180 W/
/ Ave.)
12 Screen weight 30kg/
13 MTBF >10,000 hours
14 Life span ≥100,000 hours
15 IP rating(Front/Rear) IP31/IP65
16 Temperature-operating -10ºC~45ºC
17 Humidity-operating 10%~90%
18 Controlling system Linsn
Source compatibility(with
19 AV,DVI,HDMI,SDI,S-Video,DPetc.
video processor)
Shenzhen Scenico Optoelectronics Co., Ltd. Was founded in 2008 with a registered
Capital of RMB 2 million. Scenico is a leading Turnkey Solution Provider of LED display. Scenico has over 100 Employees and over 5000 square meters'factory in Shenzhen, China.
We produces a full range of LED display, including Outdoor Die-cast Aluminum LED Display, Indoor Die cast Aluminum LED Display and Outdoor Full Color LED Display, Indoor Full Color LED Display, Outdoor Full Color Rental LED Display, Indoor Full Color Rental LED Display, LED Curtain Display, LED Grid Display, LED Floor Display and Single&Dual Color LED Display and so on. Most of Scenico's products have passed CE, RoHS, EMC, etc.
Company MileStone:
2008 Shenzhen Scenico Optoelectronic Co; Ltd was established.
2009 Enployees reached 80 persons. Annual turnover reached: USD 8 million,
2010 Oversea department annual turnover reached: USD 7 million was over 50% of total annual turnover 10.8 million USD
2011 A senior engnieer & consult team from Belgium Barco joined us
2012 Indoor & Outdoor Die-cast aluminum LED display got a good reputation from market
2013 Scenico LED display has been sold to more than 30 countries
Business Strategy:
Strict quality control as our passport to market.
Elegant& considerate service as our most important priority
Mutually beneficial interaction is our goal
Management Philosophy:
Sincerity
Teamwork
Work with happiness
Enthusiasm
Operational Objectives:
Customer Satisfaction
Quality First
Efficient and Effective
Engineering Dept.
Scenico's engineering department have 2 designing engineers,
3 project Development engineers, and 3 after service support engineers.
2 R&D engineers is just joined jus this year. Director is Genernal Enigneer Lok Luo.
Task:
1, Offer directive design for PCB, module, cabinet, display connection, structure etc
2, Assist sales to offer technical support to customer.
3, Design creative product that meet market's demand
Certificate
CE-LVD
CE-EMC
RoHS
FCC
UL
ISO 9001: 2008, ISO 14001: 2004
