Physical pixel pitch: 12 mm
Pixel configuration: 1R1PG1PB
Chip: Epistar and Silan
Module resolution: 16x 16 pixels
Module size: 192x 192 mm
Physical resolution: 80x 80pixels
Cabinet size: 960x 960x 150 mm
Physical density: 6400pixels/cabinet
Module quantity: 25pcs =5(w) x 5(h)
Material: Steel
Weight: 55Kg
Brightness: 5500 cd/m2
Brightness adjusted: 100 grade by software, or by Auto-optic induced
Color processing: 14bit
Display color: 4.4 trillion
Color temperature(k): 5000_9500 (choice by user)
Physical density: 6944 pixels/m2
Whole display flatness: 1mm juncture
Best view distance: 8m
Best view angle: Horizontal 60deg; Vertical 40deg;
Driving method: Constant driving current Scan: 1/2
Refresh frequency: 2000hz
Frame rate: 60Hz
Humidity(RH): 90~95%
Protection grade: IP65
Working Voltage: DC 5V
Power supply: AC220V, 60Hz
Average power consumption: 300 w/m2
Max power consumption: 600 w/m2
MTBF: 10000 hours
Screen lifetime: 100000 hours
Signal interface: DVI
Communication distance: Internet cable: 120m Fiber cable: 1000m
Signal transfer mode: Synchronize
