Features:
1. Retractable angle-adjustable bracket makes cabinet stackable.
2.Rubber mask reduces impact.
Technical data:
Pixel Composition: 1R+1G+1B
Pitch Pixel: 16mm
Pixel Density: 2500 Pixels/m2
Brightness: 6000CD/m2
Cabinet Dimensions: 128mm×960mm×200mm(Width×Height×Thichness)
1024mm×1024mm×200mm(Width×Height×Thichness)
Partner for Guangzhou Asian Games, Shanghai World Expo, Beijing Olympic Games, China-Asian Expo and Boao Asian Forum.
P16 outdoor full-color high-contrast LED display |
Item |
Details |
Parameters |
|
Physical |
16mm |
Pixel |
Pixel Configuration |
1R1G1B |
|
Chip |
Wave |
Brightness |
Packaging |
R |
Epistar |
625nm |
1200mcd |
Thru-hole346 |
G |
Silan |
520nm |
2400mcd |
Thru-hole346 |
B |
Silan |
470nm |
600mcd |
Thru-hole346 |
Module |
Module resolution |
16*16 pixels |
|
Module size |
256*256mm |
Cabinet |
Physical resolution |
64*48 pixels |
Cabinet Size |
1024*768mm |
Phisical Density |
3072 pixels/cabinet |
Module quantity |
24pcs=4(w)*3(h) |
Material |
steel or aluminum |
Weight |
50kg or 42kg. Approx |
Power supply(5V40A) Quantity |
5pcs |
Average power consumption |
360W/cabinet |
Max power consumption |
900W/cabinet |
Electricity Parameter |
Brightness |
7500nits |
Brightness adjusted |
100 grade by software or by Auto-optic induced |
color processing |
8 bits |
Display color |
16M |
Color temperature(k) |
7200k |
Physical density |
3906 pixels/m ² |
Whole display flatness |
≤1.2mm Juncture |
Best view distance |
9-65m |
Best viewing angle |
v≥120° H≥50° |
Storage temperature |
-40°C-+60°C |
Working temerature |
-30°C-+60°C |
Driving Method |
Constant driving current Scan: static |
Refresh frequency |
>300Hz |
Frame rate |
75Hz |
Humidity(RH) |
10%-90% |
protection grade |
Front IP65, Rear IP54 if not specified |
Wording voltage |
DC 5V |
Power supply |
AV 110V ± 10% /220V± 10% |
Average power consumption |
440W/ m² |
Max power consumption |
1100W/ m² |
MTBF |
10,000 hours |
Screen lifetime |
100,000 hours |
Control System |
Control System |
Linsn |
Signal Interface |
DVI |
Communication distance |
CAT 5 cable:≤100m Fiber cable:≥ 500m |
Signal transfer mode |
dot to dot synchronized with computer monitor |
