1) Widely used in shopping centre, square, airport, advertising and etc.
2) Environment-protection and energy-saving.
3) Advanced digital technology for video.
4) Be able to show video, cartoon, graphics, text, pictures and etc.
5) Outdoor LED display
6) High brightness
7) Light weight and ultra thin
8) Good stability
9) Professional advertising outdoor Led display, led screen Manufacturer
|
Pixel Pitch |
12mm |
|
Pixel Density(dot/m² ) |
6944 |
|
Pixel Configuration |
1R1G1B / 2R1G1B |
|
Packaged Type of LED |
DIP546 |
|
Module Size(mm) |
192X192 |
|
Module Resolution |
16X16 |
|
Brightness(cd/m² ) |
6500 - 7000 |
|
Max Power Consumption (w/m² ) |
1040 |
|
Best Viewing Distance(m) |
12-36 |
|
Viewing Angle |
120° H/60° V |
|
Drive Mode |
Constant Current drive Static, 1/2 scan / 1/4 scan |
|
Driving |
Driving IC MBI5026 / MBI5024 |
|
Frame-change Frequency |
≥ 60 Hz/s |
|
Refresh Rate |
≥ 600Hz/s |
|
Gray Grade Level |
4906 Grades |
|
Display Mode |
1024*768 |
|
Control System |
Synchronization Control |
|
Transmission Distance |
Reticle ≤ 100M; Multi-mode Fiber ≤ 500M
Single-mode Fiber ≤ 10000M |
|
Out of Control |
Rate ≤ 0.0001 |
|
Lifespan |
≥ 100000H |
|
Driving Power |
5V |
|
Working Voltage |
AC220V± 10% 47HZ~60hz |
|
Working Temperature |
-10° C ~+55° C |
|
Working Humidity |
5%RH~85%RH |
Universe Optoelectronics Co., Ltd. is a high-tech private company who combines research, development, production and Sales into one kit. It is one of the R & D and manufacturing base of the Energy and Power Institute of Huazhong University of Science and Technology, it is Also cooperate with China's State Key Laboratory of Optoelectronic.
Our company mainly engaged in the manufacturing of LED 7segment, connectors and other LED lighting products. The products are widely used in electrical appliances, computer, and lighting decorative and other fields. LED lighting products are with low energy, environmental protection and other features, which is in compliance with the global advocacy of energy saving and environment protection.
Our company covers an area of 7000 square meters, employs more than 500 people, including 120 professional R & D and technical staff. The workshop selects the advanced manufacturing system, strict quality control system and complete product inspection flow. The product has passed not only the related the ISO9001 authentication, but also the product authentication of RoHS, CE...
Company uphold the idea of managing continually, wholeheartedly and faithfully sercvice for new old customers with high technology and high quality.
