P12.5 Mesh Curtain LED Display
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Set |
| Pay Type: |
L/C,T/T,Western Union |
Features of P12.5 mesh Curtain LED Display:
* Ultra thin: only
50mm* Light weight: 6kg/panel* Panel material: aluminum
* High resolution
* Easy to carry and assemble
* Energy-saving
| Parameter | Unit | Value |
| Pitch | mm | 12.5 |
| Brightness | nits | 650 |
| Color temperature | deg. K | 6,500 |
| Viewing angle – Horizontal (50% brightness) | deg. | 120(-60~ +60) |
| Viewing angle – Vertical (50% brightness) | deg. | 120(-60~ +60) |
| Panel weight | kg | 6 |
| Panel width | mm | 400 |
| Panel height | mm | 800 |
| Panel depth | mm | 50 |
| Panel area | sq. m. | 0.32 |
| Panel material |
| Epoxy paint coated Aluminum Frame |
| Operating temperature range | deg. C | -30 to +60 |
| Humidity operating | RH | 10% ~ 90% |
| Pixel type and configuration | R/G/B | 3in1 SMD |
| Resolution per panel |
| 32x64 |
| Dot per panel |
| 2,048 |
| Dot per sq. meter |
| 6,400 |
| LED per sq. meter |
| 6,400 |
| Recommended minimum viewing distance | m | 9.5 |
| Drive Mode |
| Constant current drive |
| Colors |
| 281 Trillion |
| Grey scale (linear) | Levels | 65,536 levels per color |
| Brightness control | Levels | 100 |
| Contrast ratio |
| 1,000:1 |
| Processing depth | bit | 16 |
| Video frame rate | Hertz | 60 |
| Display refresh rate | Hertz | 180~3,000 |
| Input voltage (nominal) | VAC | 110 to 240 |
| Input power frequency | Hertz | 50 to 60 |
| Input power (max) | Watts/ panel. | 240 |
| Input power (typical) | Watts/panel. | 96 |
| Lifetime (50% brightness) | Hours | ≥100,000 |
| Red wavelength (dominant) | nm | 625 |
| Green wavelength (dominant) | nm | 525 |
| Blue wavelength (dominant) | nm | 470 |
| Multimedia data format |
| DVI,MPG,AVI,WMV,RM etc. |
| Mounting System |
| Fixed&Hanging Installation |
| Prod Model: |
LS-IM-P12.5-0.8mx0.4m |
| Brightness: |
650nits |
| Viewing Angle: |
120/120 |
| Panel Size: |
400X800 |
| Resolution Per Panel: |
32X64 |
| Panel Material: |
Epoxy Paint Coated Aluminum Frame |
| Mounting System: |
Fixed&Hanging Installation |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Display Type: |
LED Video Display |
| Application: |
Stage Performance |
| IP Rating: |
IP43 |
| Pixel Pitch: |
12.5mm |
| Pixel Configuration: |
3 in 1 SMD |
| Pixel Density: |
6400DOT/M&Sup2 |
| System Operating Platform: |
Windows7, Vista, XP, 2000, 98 |
