P10 SMD outdoor full color LED display resolution is very high. And it is specially designed for outdoor LED lamp adopted standard SMD5050 encapsulation technologies. Its advantage is high brightness and well radiating. Every light unit is composed of red, blue and green color. And its showing color is up to 10.7 billion. So it can display color full dynamic and static magic perfectly. It supports VGA, DVI, HDMI, TV video, VCD or DVD etc.
P10 SMD outdoor full color LED display adopted auto-product technology. And its feature is high reliability, high brightness,
Low power consumption, long life-span, big viewing angle. So it mainly use in Square, outdoor vocal concert, Park, Market and Golf course, etc.
Product feature:
The resolution that the display supports can be reached 1920x1080
Ultra high refresh frequency: Adopting the latest Smart-PWM technology and original brightness homogenization algorithm, which makes the LED display with ordinary general pure drive have ultra high refresh frequency (more than 4000Hz), eliminates the display's stroboscopic phenomenon, lets the shooting effect of the screen be irreproachable, and satisfies the demands of live broadcast.
The grayscale of the system can be reached 65536 levels
Supports receiving card-level intelligent online testing and fault error (optional function)
Systems support point-by-point brightness and chromaticity adjustment (optional function)
Each box's splicing uses the patent products: The adjustable slider ensures the screen body to be seamless.
The functions of the cabinet design with high protection grade are waterproof, dustproof, moisture proof, anti-corrosion, mildew proof, shockproof and anti-electromagnetism interference, and so on, it is applicable for various outdoor environments.
Adopts integrated circuit design, optimizes each electronic' space layout, goes through the strict EMI testing, which ensures the stability of the products.
Perfect display appearance, to meet the high-quality display effect, the mask has carried on the special design.
As high as 10.7 billion kinds of color performance ability, this ensures the high fidelity of image color.
| number | Item name | Parameter and index |
| unit module |
| 1 | LED encapsulation mode | 3-in-1 SMD5050 |
| 2 | Horizontal axis | 120° |
| 3 | Vertical axis | 120° |
| 4 | Pixel composition | 1R1G1B |
| 5 | Pixel pitch | 10mm |
| 6 | Scan method | 1/2 |
| 7 | Drive method | Constant current |
| 8 | Module resolution | 16× 16 pixels |
| 9 | Module dimensions | 160mm× 160mm |
| 10 | Module type | incorporated lamp and drive |
| 11 | Module working voltage | +5V |
| 12 | Module average power | 6W |
| 13 | Module maximum power | 25W |
| 14 | Module shell material | PC |
| 15 | Module mask material | PC |
| unit cabinet |
| 1 | Module layout | 6× 4 pieces |
| 2 | Cabinet resolution | 96× 64 pixels |
| 3 | Cabinet maximum power | 750W |
| 4 | Cabinet average power | 188W |
| 8 | Cabinet dimension | 960mm× 640mm |
| 6 | Cabinet material | steel/aluminum alloy |
| 7 | Cabinet color | black/gray |
| 8 | Protection grade (front/back) | IP65/IP54 |
| Entire screen |
| 1 | Application environment | outdoor |
| 2 | Brightness | > 7000 cd/m² |
| 3 | White balance coordinates | X=0.29, Y=0.31 |
| 4 | contrast | 64000: 1 |
| 5 | Color temperature | 8000K |
| 6 | Pixel density | 1000pixels/m² |
| 7 | Average consumption | 305 W/m² |
| 8 | Maximum consumption | 1221 W/m² |
| 9 | Power source | AC220V/50HZ or AC110V/60HZ |
| 10 | Operating temperature | -20 º C+50º C |
| 11 | Operating humidity | 10%-90% |
| 12 | Storage humidity | -30º C +50º C |
| 13 | Refresh frame rate | 60Hz |
| 14 | Refresh rate | 480Hz |
| 15 | Viewing distance | 10-100m |
| 16 | grayscale/color | 16.7M |
| 17 | Brightness adjustment | 100 manual /100 auto levels/100 timing |
| 18 | Control method | synchronous with the computer display |
| 19 | Data transfer range | Network; cable: 100m |
| 20 | Computer operating system | WINDOWS98 2000 XP Vista 7 |
| 21 | Video signal | VGA DVIRFS-Video RGBRGBHVYUVYCCOMPOSITION and so on. |
| 22 | MTBF | ≥ 10000 hours |
| 23 | Longevity | ≥ 100000 hours |
| 24 | Certification | UL/CE/CCC |
