outdoor advertising led screen
1. Good uniformity,Engergy saving
2. Stable capability
3. High brightness
4. factory price since 1996
warmly welcome you come to visit our factory.
1. The Purpose of Installing outdoor usage advertising led screen p10 p16
1) Creating and producing new profitable business.
2) Insuring new media using top advanced formula.
3) Providing good quality information more rapid than TV.
4) Enforcing the publicity of enterprises through having motion picture media.
5) Keeping the flexibility of creating and producing new business of new media.
6) Providing the basis of participating satellite communication and cable communication business.
2. Advantages and Main Features of BESDLED Factory price outdoor advertising led display screen
1) Having the driver and controller that is customized only for designing and manufacturing
outdoor full color P12 advertising led Screen .
2) Developing and having the unification board of motion picture control only for LED Video Screen
3) Having operating software(The Latest Version).
4) Having full experiences of the design, manufacturing and installation of LED Video Screen Board.
5) Quick Delivery during 3days - 15days
6) Easy maintenance and after sale service
7) The maximized visual effect with improved picture quality-Incorporating high brightness
LED creatives natural full color of 16 bit different colors.
8) Easy connection to any Video Input sources(S-VHS, Components,
CD/DVD Player, Satellite-Receiver, Camera and etc.).
3. full color digital led display Special Features
1) Displaying video motion pictures in high definition
With 4,096 steps of brightness control for each RED, GREEN and BLUE color,
our system is designed to provide pictures quality similar to that of analog formula, without losing image data.
2) Displaying multi(natural) colors
With 4,096 color grades of each RED, GREEN and BLUE color, our system is designed to
display multi-colors amounting 68.7 billion on the screen.
3) Windows based operating software
Our system is designed to be operated with MS Windows.
4) Providing delicate brightness adjustment
Our system is designed to provide delicate brightness adjustment(by each 0.025% steps)
5) Providing automatic brightness adjustment
Our system is designed to provide automatic brightness adjustment according to
the change of ambiance brightness.
6) Screen size adjustment
Our system is designed to adjust screen size not only to the standard ratio of 4 : 3 or 16 : 9
but also specific size as you want to use
7) Perfect transmission of digital signal
Our system is prevented from screen quiver or mis-operation because it is designed to
transmit digital signal in perfect timing between modules and main-controller.
8) Providing perfect gamma correction
Our system is designed to provide perfect gamma correction made continuously in 4,096 steps.
9) Easy for operation and maintenance
Our system is designed to be easy for operation and maintenance because circuit design is simplified.
4. BESDLED outdoor led Display Features
1) Natural Color(16,777,216 Colors) by the high-quality luminescent of RED, GREEN, BLUE- LED
2) Improved Picture Quality & Clarity.
3) Incorporating high-quality luminescent of RED, GREEN & BLUE LED elements and a large number
of pixels enables a brilliant display even in direct sunlight, and a wider viewing angle.
4) Display broadcasting full-motion picture.(YUV : 4:2:2 Format, 60 Frames / sec, Motion-JPEG/ MPEG I, II..)
5) Store data by video recording card
6) Display 3D-Animation(accept all 3D-animation formats) smoothly.
7) Display variable graphic image with variable effect.
8) Make graphic image file / text insertion at any time.
9) Broadcast News, Sports, Entertainment, Public service announcement or Special events
with Multiple video inputs(TV-Tuner, CATV, Satellite-Receiver, Camera, S-VTR and CD/DVD
Player of NTSC, PAL and SECAM)
5. Control Features
1) 256 Steps of each RED, GREEN, BLUE-LED by programmable control.
2) 64 Steps Brightness, Contrast, Saturation and Hue control by programmable control.
3) Gamma correction by time control and by programmable control.
4) Adjustment of display screen brightness according to illumination-sensor.
5) Remote control and Monitoring through Public Service Networks(TCP-IP, MODEM,
Coaxial-Cable and Optical Fiber-Cable.)
6) Remote programmable Time Schedule control.
6. Other Features of advertising led digital billboard
1) Check the error pixel by Check software.
2) Stable Operation under Microsoft Windows NT.(or Microsoft Windows 98 etc.)
3) Easy Maintenance.
4) Sequent Power ON/OFF and Auto Power ON/OFF.(use defined)
5) Remote control & monitor PC Power Supply.
For more details, please do not hesitate to contact us.
Parameters for Pixel pitch 10mm outdoor full color advertising led display
Pixel Pitch | 10mm |
Pixel Conformation | 1R1G1B |
Pixel Density | 10000 pixels/ real ; |
Module Dimension | 160×160mm |
Module Resolution | 16×16 |
Cabinet Dimension | 960×960×180mm |
Cabinet Resolution | 96×96 pixels |
Slot between cabinet | ≤0.3mm |
Weight of the LED display screen | 55kg/m2 |
Screen luminance | ≥7000 CD/m2 |
Contrast | ≥ 750:1 |
Colors | 16777216 |
Brightness uniformity | Whole Screen Luminance Discrepancy <10% |
Grey scale(typical) | Red, Green, Blue are adjustable, 256 levels respectively |
Optimal viewing Angle | H<1200,V<550 |
Optimal viewing distance | 10m-150m,vivid contents under sunlight |
Drive mode | Constant Current, 1/4 Scan |
Refresh frequency | 60 HZ/s |
LED lamp life-span (Theoretical value under ideal state) | 100000 hours |
Mean time between failures | 10000 hours |
LED Display Screen life-span | ≥ 10 years |
Scotoma ratio | <0.01%, discrete distribution |
Max. power consumption | 1,000 W/m2 |
Ave. power consumption | 450 W/m2 |
Power supply requirement | 220VAC/50HZ±10% |
Operating ambient temperature | -20+80 |
Operating ambient humidity | 10%95%RH |
Transmission speed | High Speed, 40Mbit/s |
Grade of waterproofing | Front: IP65, Back: IP54 |
And we also have the other good products as below:
Indoor PH2 PH2.5 PH3 PH4 PH5 PH6 PH7.62 PH10
Outdoor PH6 PH8 PH10 PH12 PH12.5 PH16 PH20 PH25 PH31.25 PH40
