Huasun Professinal flexible LED display Focus on the application of the stage, entertainment, DJ studios, Rental, Live concert, tour show and so on
1. Features
1)Foldable. Fold like colth, can match any shape and size of your requirement.
Like the 2D and 3D shapes such as round, triangle, cylinder, and cone, etc
2)Light. The LED Display is smart and light. Saving space and the transportation cost.
2. Installation & Maintaince
1) The LED Display is easy to Install and maintaince. No tools. Just your hand.
2) Finishing installation and debugging of 5 square meters takes just 1 hour, labor cost saving a lot.;
3. Quality
High quality with the high refresh rate. All the refresh rate of Pitch size 6mm, 7.8mm, 9.3mm, 12mm, 16mm are 10, 000Hz
4. Material
The manufacturing material is DFR which makes the displays inflammable, scratch proof, heavy duty, safe, and reliable
5. Application (indoor & outdoor)
1), The curtain IP is 54, Water-proof, fire-proof Certificate.
2), The curtain is good for indoor and temporary outdoor for a few days.
6, Factor for Quotation
1), the pitch size you need or project information
2), the height and wide of LED curtain or stage
3), Shipping address in detail.
7. Warranty:
1), Two year warranty
2), Free spare parts come with each order
3), Free train at factory
4), 24 hours technical support
8. Specifications
1, Model No.: Galaxias P6
2, Display Function: Vedio
3, Pixel: P6.25mm
4, Visual Distance: 5m
5, Density: 27778 DOT /sq. M
6, Refresh Rate: Large than 10, 000 Hz
7, Brightness(white): 2650 nit
8, Display Mode: 1280*1024
9, Average Power Consumption: 95W/sq. M
10, Max Power Consumption: 280W/sq. M
11, Recommendation moudel size: W=800mm L=2400mm T=25mm
12, Weight: 11.8kg /sqm
13, Working Voltage: DC24V
14, Brightness Level: 16 Levels
15, Bit depth per color: 16 bit
16, Bit depth per pixel: 48 bit
17, Visual angel: Horizontal: 120 degree; Vertical: 120 degree
18, Drive Mode: Constant Current
19, Signal Type: AV, S-Vedio, VGA, CVBS, HDMI, DVI
20, Operating System: Windows2000/XP/Vista/Windows7
21, Control Distance: HSYV; Within 100m
22, Face Material: DFR Velvet Drapery
23, Ingress Protection: Front IP65. Rear: IP54
24, Working Temperature: -20 ~ +50 degree C
25, Relative Humidity: 10% - 90%
26, Installation: Hang
27, Power System: Power-600, Power-1200, Power-2000
28. Safety certificate: CE FCC RoHS SGS fire test report
Huasun Technology Co., Ltd. is a high-tech enterprise that is engaged in the researching, developing, producing, marketing, and engineer service of LED display and LED lighting. It has been grown in Beijing, capital of China, for over ten years. The main products and services include LED display system, LED digital stage system, LED lighting system. With a business principle of technological innovation and professional service, the company commits to provide high-quality LED products and solutions for all clients.
The company has a R&D team made up of senior engineers. Taking advantage of the technological and cultural resource in the Capital of China, working together with experts in mechanism, optics, and electronics from the main universities, the team is devoted to the research and application of multimedia technology and has gained the leading position in product design, software development, mechanical design and optical application. The company has own many national invention patents in LED display technology. Flexible LED display, one of our patents, is a landmark product in the development of LED display. It is widely used by the clients from all over the world for the advantages of compact size, light weight, and easy installation. We always keep in mind that the mission and responsibility of the enterprise is to change the world by pioneer spirit and innovative product in a technology high speed age. We are always proud of it.
Welcome to future of Huasun: A brighten future.
