Outdoor PH10 Stage LED Display

Outdoor PH10 Stage LED Display
Price: Negotiable/Piece
Trade Terms: FOB
Min Order: 5/Piece
Pay Type: T/T
Outdoor PH10 Stage LED Display:

High quality with competitive price
For stage, business performance
Display video, text, graphics
Item PH10
Pixel Pitch 10mm
Pixel density 10, 000
LED Encapsulation DIP 346
Pixel Configuration 1R1G1B
Module Resolution 32× 32
Module Size 32× 32
Driving Mode 1/4 scan
Cabinet Style Die-casting cabinet/iron cabinet
Assemble Method fast lock/fixed
Min. Viewing Distance ≥ 10 meters
Brightness 5500 - 7500 cd/sqm
Viewing Angles H 120° V 50°
Weight 640 * 640 mm, 17 kg/cabinet, < 36 kg/sqm
Max. Power Consumption 700 W/sqm
Working Voltage 220V ± 15% or 110V ± 15%
Working Temperature & Humidity -20C - +50C / 10% - 90%
Store Temperature & Humidity -30C - +60C / 10% - 90%
MTBF ≥ 9, 000 h
Life Time ≥ 50, 000 h
IP degree ≥ IP65
Certificate CE, RoHS, FCC, CCC
Malfunction dot rate < 1/10, 000
Control System synchronous
Driving device constant current driving
Grey Scale 16
Color 16.7 M
Frame Frequency ≥ 60Hz
Refresh Rate ≥ 1350Hz
Computer Operating System WINXP, WIN2000, WIN98 etc.
Signal RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION etc. synchronous system
Control system PCTV card(Optional)+ DVI video card + chief control card + fiber optics transfer(Optional)
Software LED Studio(synchronous system)/Specialized asynchronous software or Customer self-develop software(asynchronous system)
Prod Model: PH10
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Pixel Configuration: 1R, 1G, 1B
Pixel Pitch: 10mm
Pixel Density: 10000 dot / m²
IP Rating: IP65
Tube Chip Color: Full Color
Display Function: Video Display
Scanning Mode: Static Scan
Average Power Consumption: 350W / m²
Certification: CE
Shenzhen Leder Electronics Co., Ltd. Locates in E Building, the new world of Science and Technology Industrial Park, XiaShiJia, Gongming Street Guangming New Area, ShenZhen, Guangdong, China. LEDER is the high & new technology enterprise specializing in the Research & Development of LED displaying products, production, sales, engineering service, etc.

Based on more than 10 years of outstanding development, LEDER becomes one of the most advanced LED display manufacturers in China and also one of the biggest professional LED display manufacturers in Southern China.

With modern workshop for electronic processing, assembling, adjusting and aging, LEDER ensures the production capability of 20000 m2 LED display for all types yearly, and is able to provide one package service for our clients from consultant, production, installation, adjustment & test, training to after service.

LEDER positively practices the environmental protection and energy saving. In 2008, LEDER firstly launched OUTDOOR SMD (5050, 5060) 3IN1 FULL COLOR LED DISPLAY. Solved 3 difficult problems on outdoor SMD LED Displays successfully - brightness, heat extraction and water proofing, and made-up deficiencies of the traditional LED Display of small viewing angle, module's nonuniform color, large power consumption, overweight, and so on. In 2009, LEDER brought out LED lighting products: Flexible LED video strip, LED flexible strip, LED video pels light, LED module^^, which attracts batches eyes and gains very good comment from experts and audients.

Since the foundation, LEDER has been insisting the tenet of "Build first-class brand, win with superior quality and service", and has actively conducted the ISO 9001 system, its products have been awarded certificates such as CE, RoHS. Besides owning a few of independent core technology and patents, LEDER firstly built up the enterprise standard, which effectively promotes the healthy development of Chinese LED display industry. Successively, LEDER undertakes batches of high quality projects in domestic and oversea. Now LEDER has jumped to be the biggest professional LED display manufacturer in ShenZhen, and has set up its leading position in optoelectronic industry, and to be as sponsors at the 16th Asian Games.

LEDER's General Manager has been directly working on the management of R&D, production, engineering, and after-service for more than 15 years. He has experienced the stage of starting, developing and maturing of China's LED Display industry. He would like to cooperate with all customers, leading all of LEDER staffs, to witness the prosperity of LEDER and LED Display industry together.

"Share our successful happiness with our clients" is the business concept we always keep. With your continuing care and support, we, together enter to LED products' energy saving, colorful, and bright future.
