LED outdoor full color is called LED video wall as well. It is used to display video. Any signal input can be matched such as DVI, S video, DVD, VCD, TV, Live camera etc. It is widely used in the modern city as an attractive advertising sign.
LED Lamp Specs:
- Configurations: 2 Red, 1 blue & 1 Green.
- Viewing Angle: H=120, V=60.
Module Specs:
- True Pitch=20mm;
- True Resolution=16 x 8; Virtual Resolution=32 x 16
- Module Dimensions=320mm x 160mm
Cabinet Specs:
- Module Layout = 4 x 6
- Cabinet Dimensions = 1280mm x 960mm x 190mm
LED Display Specs:
- Brightness: >7, 000 nit
- Contrast: >64000: 1
- Grayscale: 64k
- Scan Rate: 1, 000Hz
- Refresh Rate: 60-85Hz
- Transformation: Virtual/True
- Maximum Resolution: 1024 x 768 / 1280 x 1024
Other
- The chips are 14mil LED display special chips, and they are antistatic for over 5000V.
- The copper brackets and silica gel have high quality, and they are electric, heat-dissipated, and anti-ultraviolet ray.
- Professional spectral and color separation standard have ensured the coherency of the display's color.
- The materials of PCB accord with the standards of UL certification, and the copper on them are over one ounce.
- All connectors are phosphor copper, and they are plating for 2μ, so they are acid-resistant and alkaline-resistant.
- The display is accordant with RoHS standards.
Shanghai Xindianshi Electronic Technology Co., Ltd. Established in 2001, is a collection of electric light source research and development, production, sales and engineering design for the installation of an integrated high-tech enterprises, factory building area of 20000 m2, and more than 300 employees. Now the company has five production lines, one SMT production line, two LED assembly lines, two LED production lines with annual capacity of 1 million pieces. All products are achieved CE, RoHS and other international certification, and the products are widely used in industrial, commercial, organs, schools, hospitals and other lighting places.
We have more than twenty junior and senior professional study design staff and a group of independent of high-quality foreign trade elite team, and has a long-term strategic cooperative relation with fudan university institute of electric light source. Annually exporting proportion accounts for 70% of the volume of production, , mainly export to Europe, North America, South America, Middle East, Africa and other dozens of countries and regions, got the trust and praise from domestic and abroad customers. Our company has successfully undertaken the Shanghai world expo Brazil hall, taicang TV tower and other major projects, and with high efficiency, high quality win back a good reputation.
"Quality first, Sincere service, Win-win cooperation" is our management concept, we insist on the principle of quality first as our life, we would offer assured products and best service for our customers, and try our best to build a harmonious win-win business relationship. You would be relieved with our wholehearted effort, with our sincere heart to bright your life, to bright your world!
