High quality commercial advertising outdoor full color LED display
IP 65
Hihg birghtness and low consumption
Easy stallation
Synchronized with PC
Static driving
Viewing angle: H120/ V60
Frame rame: 60Hz
Refresh rate: More than 400Hz.
Sunrise high quality outdoor LED display, engineered for sports venues, outdoor theaters, theme parks and billboard installations etc.
Broad view angle
Passed CE & RoHS
2 yeasr warranty
Aluminum modules
Technical Specifications
Pixel pitch: 16mm
Brightness: 6500nits
Pixel configuration: 2R1G1B
Cabinet dimension: 1024*768mm
The best viewing distance: 16-150m
Driving method: Static constant current
Max power: 1650W
Average power: 700W
Viewing angle: H 120 degree, V 60 degree
Driving voltage: 5V
Weight: 60KG/m2
Data sending distance: 100 meters(UTP Category5. No relay) 850 meters(multi-mould optical fiber)
10Km (monomode fiber)
Brightness adjustment: Automatically or manually
Working temperature: -20 degree ~ 60 degree
Performance humidity: 10% ~ 90% RH
Color temperature: 6500K
Assembly precision between PCB: Lower than 1mm
Screen uniformity: Lower 1.55mm
Gray scale /color: RGB 16384 rade/Each.
Every year we sell over 1, 000 m2 to the worldwide, all LED displays only use high quality LEDs and have passed CE and RoHS. We are working with some credible companies in other countries like Australia, France, Italy, Russia, Kuwait, Egypt, etc to develop the markets and win good respect from our customers.
In order to supply reliable products with competitive prices, we are sourcing excellent materials and parts for our LED display, and build a good business cooperation with our suppliers, a long term working together with CREE, Nichia, Meanwell, etc companies, all our LED displays are completed under ISO9001: 2000, implement twice aging test totally 72 hours as well as waterproof, vibration testing to ensure quality before shipment.
Because of our good quality, we can guarantee our customer good after sales service. Our products have at least 1 year warranty, some of them have 2-3 years warranty. To help our customers complete LED display, we execute a comprehensive customer-caring and training system to make our customers simply run LED display.
We are expecting an everlasting cooperation with you!
