| Price: | US $ 1043-1135/Square Meter |
|---|---|
| Trade Terms: | FOB,EXW,CIF |
| Min Order: | 1/Square Meter |
| Pay Type: | L/C,T/T,Western Union |
|
Display and control feature |
Structure feature |
||
|
Specification |
Parameter |
Specification |
Parameter |
|
Pixel Pitch |
16 mm |
Module size |
256 mm*128 mm |
|
Pixel composing |
2R1G1B |
Display resolution/module |
16 dots*8 dots |
|
Wavelength (R) |
625±5 |
Standard cabinet size |
1024 mm*768 mm |
|
Wavelength (G) |
522±3 |
Weight per sqm |
65 Kg/sqm |
|
Wavelength (B) |
567±3 |
Protection classification |
IP65 |
|
Wave Angle (H) |
140°(H)/ 60° |
Install mode |
Wallmount, hung and stand structure |
|
LED package |
DIP546 |
Cabinet Material |
Iron/Aluminum |
|
Density per sqm |
3906 pixel |
Working power |
|
|
Display color |
256*256*256 |
Specification |
Parameter |
|
Whiteness brightness |
≥7000 |
Working voltage |
AC 220v/380v±10% 47~64Hz |
|
Brightness level |
128 grade |
Max power/sqm |
1100W/sqm |
|
Changing frame frequency |
60 Hz |
Average power/sqm |
700W/sqm |
|
Refresh |
400 Hz |
Short circuit protection |
Yes |
|
Driving method |
Constant Static |
|
|
|
Control mode |
synchronous |
Working environment |
|
|
Display port |
DVI |
Specification |
Parameter |
|
Display mode |
1024*768 /1024*1024 |
Environment |
Outdoor |
|
Out of control |
1/10,000 ( scattered) |
Working temperature |
--20~50 |
|
lifetime |
100,000 hours |
Working Humidity |
10~90% |
| Prod Model: | HX-OF16 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Place Of Origin: | China (Mainland) |
| Brand Name: | Harse |
| Usage: | Outdoor |
| MOQ: | 2 Square Meters |
| Size: | Customised |
| Tube Chip Color: | Full Color |
| IP Rating: | IP65 |
| Pixel Configuration: | 2R, 1G, 1B |
| Pixel Pitch: | 16mm |
| Display Function: | Video Display |
| Scanning Mode: | Static Scan |
| Certification: | FCC |
| Average Power Consumption: | 600W / m² |
| Pixel Density: | 3906 DOT Per Square Meter |
