Features & Characteristic:
Patent multi- function design, suitable for all projects
5-5-10 year warranty
Osram/Cree LED chips, 120 lm/w system efficiency*
80% lumen maintenance over 50, 000hours
0-10Vdc dimming driver available
Photocell sensor system available
Microwave motion sensor system available
Built-in surge protection
Built-in thermal protection
Maintenance free
Mercury free, No UV or IR
Universal input without additional adapter, 80-315Vac, 80-400Vdc
Instant start and flicker free
High uniformity and color rendering
|
Item Name: |
Compact Genius General Light |
|
Model: |
ZHGL-30A |
ZHGL-60A |
ZHGL-90A |
ZHGL-120A |
ZHGL-150A |
ZHGL-180A |
|
Powder Consumption |
LEDs: |
25W |
50W |
80W |
108W |
135W |
162W |
|
Driver: |
5W |
10W |
10W |
12W |
15W |
18W |
|
Total: |
30W |
60W |
90W |
120W |
150W |
180W |
|
Initial Lumen Flux: |
3600lm |
6600lm |
10800lm |
14400lm |
18000lm |
21600lm |
|
Replace HID Lamp: |
50-100W |
100-150W |
150-250W |
250-300W |
300-400W |
400-500W |
|
Dimension: |
360*323*163mm |
|
New Weight: |
8kg (17.6lbs) |
|
Color Temperature: |
4000K(warm white)/6000K(cool white) |
|
Color Rendering: |
>=Ra75 |
|
Working Life: |
>=50000Hrs |
|
Housing: |
Copper Free Aluminum |
|
Finish: |
Cathode EPD |
|
IP Class |
IP65 (Upgrade to IP67) |
|
Insulation Class |
Class I(Upgrade to Class II) |
|
Working Temperature |
-40C~60C |
|
Working Humidity |
10%~95% |
|
AC Input |
80~315Vac, (375Vac available on request) |
|
DC Input |
80~400Vdc, (12Vdc, 24Vdc and other input available on request) |
|
THD |
<10% |
|
Power Factor: |
>=0.98 |
|
Warranty: |
LED Module: |
5 Years |
|
|
Driver: |
5 Years |
|
|
Housing: |
10 Years |
Xi'an Zhihai Power Technology Co., Ltd. Was established in 1998, before 2006 we were one of the most advanced provider of power supply and we worked with many important companies in Asia, including China guodian, China mobile, and comba telecom etc.
In 2006, adopted the technology of our electronic and thermal control experience, we started and moved to the R&D, manufacture, sales and service of LED lighting, and very quickly, we became one of the leading and most professional LED lighting company in China.
Technology and quality are always playing key roles on zhihai philosophy, we are holding the "xi'an LED lighting engineering laboratory" which is authorized and supported by China national development and reform commission, and we are also holding the "shaanxi LED lighting technology and research center" which is authorized and supported by China national science and technology ministry. We have more than 10 professors and doctors in our company R&D DEP. And more than 30% of our employees have bachelor or higher degrees and fully trained.
Till 2012 we have 125 patents and more than 80 patents are pending, the patents include the LED chips packaging, power supply controlling and design of lamp housing. We worked with ISO-9001 quality control system since 2001 and the products are TUV, UL, CE and RoHS certificated.
We are working on high power LED lighting products, and more than manufacture, we are also providing our clients with lighting layout design and brightness calculation of projects. Zhihai would always be your first choice of professional LED lighting supplier.
