Real 3W Osram LED
Constant current Power supply with PDF
Warranty: 3 years
hand with hand power cables and singal cables
Feature:
1. Use constant current power supply which protect |
LED from burning and guarantee the lifetime |
2. Users can change the current themself through |
LCD display to guarantee the lifetime of LED (because sometimes |
the current is big and can burn the LED or shorten lifetime of LED) |
3. R,G,B,W (four colour) which produce millions of mixing colours |
and can produce R,G,B,W independently. |
4. With 3-pin or 5-pin XLR singal interface or hand by hand |
(power can by power cable or signal cable by signal cable) for choices |
Specifications:
Power comsumption | 200W |
Light Source | 54pcs×3W LED |
Colour for option | W(36). Warm WhiteA(18). R(12).G(18).B(18).W(6). R(18).G(18).B(18) |
Control | DMX, master slave, sound actived, auto mode |
Channel | 4/8CH or 3/7CH |
Beam Angle | 25°or 45°for option |
Display | Digital Screen |
Non-waterproof | |
Size: | (D)13X(D)22X(H)23MM |
N.W. | 3.0KGS |
G.W. | 14KGS (4PCS/CTN) |
Carton size: | 54X54X39CM(4pcs/carton) |
6pcs/Flycase size: | 76(L) X 50(W) X 60(H) |
8pcs/Flycase size: | 100(L) X 50(W) X 60(H) |
8pcs/Flycase G.W. | 35KGS |
DMX Channel:
CH1 A001 | CH2 D001 | Channel | Value | Function |
1 | | Dimmer | 0~255 | |
2 | | Strobe | 0~5 | On |
6~10 | Off |
11~100 | Impusle strobe(slow to fast) |
101~150 | gradual-on strobe(slow to fast) |
151~200 | gradual-off strobe(slow to fast) |
201~255 | sudden strobe(slow to fast) |
3 | | Effect/Mode | 0~5 | Manually change colour(R,G,B...) |
6~50 | colour change(fade) |
51~100 | colour change (gradual on) |
101~150 | sudden colour change |
151~200 | Auto(Unused for other channel) |
201~255 | Sound(Unused for other channel) |
4 | | Speed | 0~255 | Ch3 work,control speed of colour changing or auto |
5 | 1 | Red | 0~255 | Linear dimming |
6 | 2 | Green | 0~255 | Linear dimming |
7 | 3 | Blue | 0~255 | Linear dimming |
8 | 4 | White | 0~255 | Linear dimming |
Xiang Jun Lighting Service
Factory | Guangzhou Xiangjun Lighting Equipment Co., Ltd. |
Brand | Xiangjun |
Price term | EXW price/FOB Shenzhen or guangzhou |
Min quantity | 1 set |
Payment terms | T/T, Western union |
Shipping Way | 1.By Express ( DHL, Fedex, Ups, EMS) 2.By Air 3.By Sea |
Sample time | 1-3 business days |
Production time | 5-20 days, but ultimately subject to order quantity |
Packing | 1.Using EPE packing the goods in case damage 2.Then put it into the Standard carton 3.Flightcase optional |
OEM | Available |
Warranty | 1 year |
After-sell Service | 1.If there is a problem with the product, please describe it and sent the necessary picture or video to us for analyzing. 2.Then we will guide you how to fix it and provide free accessories if required.. 3.For big problem, you can send the products to our factory, then we will send a new one to you! 4 We also could use remote control to handle with problem for you |
Used for | Stage/disco/KTV/night club//bar/big show/party/wedding,some other kinds entertainment places and so on. TV, station outdoor performance, high-rise buildings,Sports, Hotels, Parks, amusement parks,Tourist attractions |
