Feature:
1.12pcs CREE 10w rgbw 4in1 leds
2. Rotating lens, can make beam and flower effect
3. Factory supply, compective price
Specification:
PPL-M1241ZB
Output voltage: AC100-240V 50/60Hz
Power consumption: 145W
The light source: 12*10W 4 in 1 Cree LED
Channel: 18/29 DMX channel
Pan: 540° With controllable speed
Tilt: 200° With controllable speed
Optical angle: 8 degrees
Electronic smooth light: 0-100%
Electronic stroboscopic pulse and random effect
High efficiency, low energy consuption
A variety of color, strong power ful beam effect, extremely fast and precise movement
Net / gross weight: 5.5/6.5kgs
Packing size: 34*25*46kgs
DMX Channel:
| CH MODE | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 | 17 | 18 |
| 18CH | PAN ROTATION | TILT ROTATION | PAN FINE | TILT FINE | PAN/TILE MOVEMENT SPEED | GENERAL DIMMING | GENERAL STROBE | R DIMMING | G DIMMING | B DIMMING | W DIMMING | COLOUR SELECTION | 4PCS OF SECTIONS GOBO SELECTION | BUILT IN PROGRAM | BUILT IN PROGRAM SPEED | EFFECT GOGO POSITION | XY MOTOR |
|
| CH MODE | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 | 17 | 18 |
| 29CH | PAN ROTATION | TILT ROTATION | FINE PAN | TILT FINE | PAN/TILE MOVEMENT SPEED | GENERAL DIMMING | GENERAL STROBE | R1 DIMMING | G1 DIMMING | B1 DIMMING | W1 DIMMING | R2 DIMMING | G2 DIMMING | B2 DIMMING | W2 DIMMING | R3 DIMMING | G3 DIMMING | B3 DIMMING |
| 19 | 20 | 21 | 22 | 23 | 24 | 25 | 26 | 27 | 28 | 29 |
|
|
|
|
|
|
|
| W3 DIMMING | R4 DIMMING | G4 DIMMING | B4 DIMMING | W4 DIMMING | COLOR SELECTION | BUILT-IN PROGRAM | BUILT-IN PROGRAM SPEED | EFFECT GOBO POSITION | X/Y MOTOR REVERSING FUNCTION | RESET AUTO-RUNNING&SOUND -ACTIVATION |
Guangzhou Baiyun Popular Stage Light Equipment Factory is a professional stage lighting manufactory which provides integrated services of research, production, marketing, after-sales inquiry, repair and maintenance. Our equipment are widely used in professional theater, entertainment centers, bars, parks, clubs, nightclubs and multifunctional units of conference halls. Compliant with CE and RoHS standards, our products main involve LED moving head lights, LED PAR lights, controllers, Moving head light, etc.
with strong beliefs in "Practical, Professional & Powerful" to the products, the company provides remarkably superb lighting Performance to all Professional Audience.
Hope we can grow together on the coming days.
